Overview

What this SWMS covers

Cable hauling is the process of installing electrical cables through pre-installed conduit systems, cable ladder trays, underground duct networks, and overhead cable routes in construction and infrastructure projects. This work ranges from small residential cable runs of 10 to 20 metres through PVC conduit to major commercial and industrial installations involving hundreds of metres of heavy power cables pulled through underground concrete ducts or building risers. Cable types include single and multicore power cables from 1.5mm² residential circuits to 240mm² or larger industrial feeders, control cables for building management systems, data cables for communications infrastructure, and specialised cables including fire-rated circuits and instrumentation cables. Manual cable hauling suits shorter cable runs typically under 30 metres with lighter cables up to 10mm² where pulling force does not exceed safe manual handling limits. Workers position at pulling end drawing cable through conduit using steady pulling force while second worker at feeding end manages cable drum rotation and prevents cable twisting or binding. Communication between pulling and feeding positions uses two-way radios or mobile phones as visual contact is often impossible due to cable route configuration. Pulling technique requires smooth steady pulls avoiding jerking that damages cable insulation or overloads workers. For bends in conduit runs, cable pulling lubricant reduces friction allowing longer pulls without exceeding safe pulling tension. Winch-assisted cable hauling becomes necessary for longer runs exceeding 30 metres, heavier cables above 10mm², multiple cables pulled simultaneously, or routes with multiple bends creating high friction. Electric or hydraulic cable winches attach to cable pulling eye or grip providing controlled mechanical pulling force. Winches incorporate load cells or tension monitoring displaying real-time pulling force allowing operators to stay within cable manufacturer maximum pulling tension specifications. Typical single-core 35mm² cable permits maximum 8kN pulling tension while 185mm² cable allows 30kN. Exceeding limits damages conductor strands, stretches cable insulation, or causes complete cable failure requiring replacement. Winch operators maintain constant communication with feeding crew adjusting pulling speed to match feeding rate and stopping immediately if binding occurs. Underground cable installation through concrete or PVC duct systems presents particular challenges including confined space access to pits and manholes where feeding and pulling operations occur. Cable drums for major underground runs can weigh several tonnes requiring crane lifting to installation position. Duct systems may be partially blocked with construction debris or water accumulation requiring clearing before cable pulling commences. Pull ropes or draw wires install through ducts using rodders or air-blown methods before cable pulling. Multiple cables may be pulled through single ducts requiring careful spacing and bundling preventing cable crossing that increases friction dramatically. Cable routes through buildings involve vertical risers, ceiling spaces, plant rooms, and sub-floor areas all presenting access and coordination challenges. Working height varies from underground pits to elevated cable tray installations requiring diverse access equipment and height safety controls. All cable hauling work requires coordination between multiple trades including electricians installing cables, civil contractors providing duct access, crane operators positioning cable drums, and traffic management for work in roadways or public areas.

Fully editable, audit-ready, and aligned to Australian WHS standards.

Why this SWMS matters

Cable hauling presents significant manual handling hazards that cause musculoskeletal injuries in electrical workers. Pulling heavy cables through conduit systems generates substantial forces particularly over long distances or through multiple bends. Single workers applying excessive pulling force sustain back injuries, shoulder strains, and upper limb injuries. Even with mechanical winches, positioning heavy cable drums, handling cable ends, and guiding cables through entry points involves manual handling of loads weighing 10 to 50 kilograms. Cable drums themselves present handling hazards - industrial cable drums can weigh 1 to 3 tonnes requiring mechanical lifting equipment. Manual rolling or repositioning of heavy drums causes crush injuries if drums tip or roll uncontrolled. Australian WHS legislation requires elimination or minimisation of manual handling risks through mechanical aids, work organisation, and correct techniques. Confined space entry hazards occur frequently during underground cable installation through pit and manhole systems. Standard electrical pits are 1.8 metres deep with restricted access via 600mm diameter opening. These confined spaces present oxygen depletion risks particularly in new concrete pits where chemical reactions consume oxygen, accumulation of heavier-than-air gases including argon or carbon dioxide in low-lying pits, and limited ventilation creating heat stress. Confined space regulations require atmospheric testing before entry, continuous air monitoring during occupation, mechanical ventilation, emergency retrieval equipment, and trained standby personnel. Cable hauling crews entering pits to feed cables, connect pulling eyes, or guide cables through duct entries must follow formal confined space procedures. Failure to implement these controls has caused fatalities when workers were overcome in confined pits. Entanglement and entrapment hazards exist throughout cable hauling operations. Cable pulling through conduits under tension creates forces ranging from hundreds of Newtons to tens of kilonewtons. If workers become entangled in moving cable or if loose clothing, gloves, or tools catch on moving cable, severe injuries result. Cable under tension that breaks or pulls free from pulling grip creates whiplash hazard with released cable striking workers. Workers have sustained serious injuries including amputations when hands or limbs become caught between cable and conduit entry points during pulling. Never place hands near cable entry points while pulling is occurring. Maintain safe distances from cables under tension. Stop pulling immediately if clothing or equipment becomes caught on cable. Electrical contact hazards arise when cable installation occurs near existing energised electrical services. Pulling cables through switch rooms, electrical risers, or plant rooms may occur near live switchboards or bus bar systems. Using metal cable pulling equipment including grips, jacks, and winch cables near energised equipment creates electrocution risk if contact occurs. Underground duct installation sometimes encounters existing buried electrical cables not identified in service location searches. Drilling or excavating for cable pit access can contact energised underground cables causing electrocution and arc blast. All cable routes require comprehensive service location before commencing work. Maintain minimum approach distances from known electrical services. Assume all services are live unless confirmed isolated and tested. Through comprehensive SWMS implementation addressing manual handling, confined space entry, entanglement prevention, and electrical safety, cable hauling can proceed safely delivering critical electrical infrastructure.

Reinforce licensing, insurance, and regulator expectations for Cable Hauling Safe Work Method Statement crews before they mobilise.

Hazard identification

Surface the critical risks tied to this work scope and communicate them to every worker.

Risk register

Manual Handling Injuries from Cable Pulling Forces

High

Pulling electrical cables through conduit systems generates substantial forces depending on cable weight, friction in conduit, and number of bends in cable route. Workers applying manual pulling force can exert forces up to 250 Newtons but sustained pulling at this level causes shoulder, back, and upper limb injuries. Long cable pulls requiring sustained effort over 10 to 30 minutes compound injury risk. Jerky pulling technique when cable binds creates force spikes exceeding safe limits. Workers pulling together without coordination may apply unequal forces increasing injury risk for individuals. Heavy cable handling during setup, drum rotation, and termination involves lifting and positioning loads weighing 10 to 50 kilograms.

Consequence: Musculoskeletal injuries including lower back strain and disc damage, shoulder rotator cuff tears, elbow and wrist strain injuries, and hernias. Chronic conditions from repeated cable pulling including degenerative joint and soft tissue disorders. Acute injuries from force spikes when cable suddenly releases from binding.

Confined Space Hazards in Cable Pits and Manholes

High

Underground cable installation requires entry into electrical pits and manholes that are confined spaces typically 1.8 to 3 metres deep with restricted access through 600mm openings. These spaces present oxygen depletion from chemical reactions in new concrete, accumulation of heavier-than-air gases from surrounding soil, and limited natural ventilation. Heat stress occurs in summer when pit temperatures exceed 40 degrees Celsius. Difficult egress through small access openings delays rescue if injury or illness occurs. Workers entering pits to feed cables, connect pulling equipment, or manage cable laying may remain in confined space for extended periods.

Consequence: Asphyxiation from oxygen depletion or toxic gas accumulation causing unconsciousness and death within minutes. Heat stroke from extreme temperatures in confined pits. Entrapment following injury with delayed rescue due to difficult access. Secondary injuries to rescue personnel attempting untrained confined space rescue.

Entanglement and Entrapment in Moving Cable

High

Cable under pulling tension moves through conduit systems with forces ranging from hundreds of Newtons to tens of kilonewtons. Workers positioned near cable entry or exit points risk entanglement if clothing, gloves, or body parts contact moving cable. Cable whip if pulling grip fails or cable breaks creates violent release of tension with cable striking nearby workers. Placing hands near conduit entry points while cable is pulling risks catching fingers or hands between cable and conduit edge. Cable loops or loose cable on ground creates trip and entanglement hazard. Rotating cable drums present entanglement points where cable unspools.

Consequence: Traumatic amputation if limbs caught between cable and fixed structure. Severe crushing injuries from high-tension cable entanglement. Lacerations and impact injuries from cable whip when tension is released. Falls from entanglement in loose cable causing fractures and head injuries. Entrapment in rotating cable drums causing severe injuries.

Excessive Cable Pulling Tension Causing Cable Damage

Medium

Pulling cables beyond manufacturer maximum tension limits damages conductor strands, stretches insulation, or causes complete cable failure. Damage may not be immediately visible but compromises long-term cable integrity. Pulling through blocked or misaligned conduits generates excessive friction. Multiple bends in cable route compound tension buildup. Inadequate lubrication increases friction. Winch operators without tension monitoring cannot detect when safe limits are exceeded. Cable damage requiring replacement wastes materials and labour while compromising electrical system safety.

Consequence: Cable insulation damage creating electrical faults and fire hazards after energisation. Conductor strand breakage reducing current capacity and creating overheating points. Complete cable failure during pulling requiring removal and replacement. Long-term reliability issues from stretched insulation. Warranty voidance on damaged cables requiring project cost recovery.

Electrical Contact with Existing Energised Services

High

Cable hauling through electrical switch rooms, risers, and plant rooms occurs near existing energised electrical equipment including switchboards, bus bar systems, and distribution panels. Using metal cable pulling equipment including grips, jacks, and winch cables near energised equipment creates electrocution risk. Underground duct systems may be located close to existing buried electrical cables. Excavation for pit access or drilling for new duct entries can contact energised underground cables. Service location plans may be inaccurate or incomplete. Cable routes through ceiling spaces may pass near concealed electrical wiring.

Consequence: Electrocution from contact with energised equipment causing cardiac arrest and death. Arc flash incidents when metal tools contact live conductors causing catastrophic burns. Underground cable strikes causing electrocution and explosive release of arc energy. Falls from electric shock causing secondary injuries. Project delays and equipment damage from electrical contact incidents.

Heat Stress During Cable Hauling in Extreme Conditions

Medium

Cable hauling is physically demanding work generating high metabolic heat load. Working in confined pits during summer exposes workers to temperatures exceeding 40 degrees Celsius with poor ventilation. Ceiling space cable installation occurs in roof cavities where temperatures reach 50 to 60 degrees Celsius. Physical exertion from sustained cable pulling compounds heat stress effects. Inadequate hydration during extended pulling operations accelerates heat-related illness. Workers wearing protective clothing including long sleeves and gloves face additional heat stress.

Consequence: Heat exhaustion causing weakness, confusion, and inability to continue work safely. Heat stroke causing organ failure, brain damage, and death if not treated immediately. Dehydration impairing judgment and increasing likelihood of mistakes leading to other incidents. Falls and injuries from impaired cognition due to heat stress.

Underground Service Strikes During Excavation for Cable Pits

High

Excavating for cable pit access or installing new underground duct systems may contact existing underground services including electrical cables, gas pipes, water mains, and telecommunications conduits. Service location plans may be incomplete or inaccurate particularly in older urban areas. Hand-held non-destructive locating equipment has limitations in detecting some service types. Striking energised underground electrical cables causes electrocution and arc blast. Gas pipe strikes create explosion and asphyxiation hazards. Water main strikes cause flooding and ground instability.

Consequence: Electrocution and arc blast from electrical cable strikes causing death and severe burns. Explosion and fire from gas pipe strikes. Flooding and trench collapse from water main strikes. Service disruption affecting customers and infrastructure. Project delays and financial penalties. Prosecution under WHS and utility protection legislation.

Control measures

Deploy layered controls aligned to the hierarchy of hazard management.

Implementation guide

Mechanical Cable Winches for Long or Heavy Pulls

Engineering Control

Eliminate manual cable pulling for runs exceeding 30 metres, cables larger than 10mm², or multiple cables pulled simultaneously by using electric or hydraulic cable winches. Winches provide controlled mechanical pulling force eliminating manual handling strain. Select winches with integrated tension monitoring displaying real-time pulling force allowing operators to stay within cable manufacturer specifications. Position winch at pulling end with secure anchorage preventing winch movement during operation. Use proper cable grips or pulling eyes transferring tension to cable structure rather than conductors.

Implementation

1. Assess cable run distance, cable size, and estimated pulling force requirements before selecting pulling method 2. For runs exceeding 30 metres or cables above 10mm², specify mechanical winch pulling in method statement 3. Select winch capacity providing minimum 2:1 safety factor above estimated maximum pulling force 4. Verify winch incorporates tension monitoring - load cell or hydraulic pressure gauge indicating actual pulling force 5. Determine cable manufacturer maximum pulling tension from cable specifications - typically 50N per mm² conductor area 6. Set winch tension limit alarm or monitoring to warn when approaching 80% of maximum permitted tension 7. Position winch at pulling end with secure anchorage to structural elements capable of resisting maximum pulling force 8. Install cable grip or pulling eye on cable end following manufacturer instructions ensuring proper attachment 9. Brief winch operator on maximum pulling force limits, communication protocol with feeding crew, and emergency stop procedures 10. Maintain constant communication between winch operator and feeding crew adjusting pulling speed to match feeding rate 11. Stop pulling immediately if binding occurs, tension exceeds limits, or communication is lost with feeding crew

Confined Space Entry Procedure for Cable Pits

Administrative Control

Implement formal confined space entry procedure for all work in cable pits and manholes. Conduct atmospheric testing before entry measuring oxygen level, flammable gases, and toxic gases. Provide continuous mechanical ventilation using portable blowers. Require continuous atmospheric monitoring with personal gas detectors. Position trained standby person at pit opening with emergency retrieval equipment. Establish communication protocol between pit worker and standby person. Limit time in confined space implementing work rotation. Brief all workers on emergency procedures and rescue arrangements.

Implementation

1. Identify all cable pits and manholes as confined spaces requiring entry procedure before commencing cable installation 2. Conduct pre-entry atmospheric testing measuring oxygen content (must exceed 19.5%), flammable gas (must be zero), and toxic gases 3. Position portable blower at pit opening providing forced ventilation before and during occupation - minimum 8 air changes per hour 4. Brief workers on confined space hazards, entry procedure, communication protocol, and emergency rescue arrangements 5. Issue personal gas detector to each worker entering confined space - calibrate detector before use and set appropriate alarm levels 6. Position trained standby person at pit opening who does not enter space and maintains visual or voice contact with entrant 7. Provide emergency retrieval equipment including tripod and winch, rescue harness, and retrieval line attached to entrant 8. Establish communication protocol - entrant responds to standby person checks every 5 minutes; failure to respond triggers rescue 9. Limit continuous time in confined pit to maximum 30 minutes in hot conditions before rotating workers to fresh air break 10. If gas detector alarms activate, immediately evacuate confined space and re-establish ventilation before re-entry 11. Never allow standby person to enter confined space for rescue - standby person summons trained rescue team

Exclusion Zones Around Cable Under Tension

Administrative Control

Establish minimum 2-metre exclusion zones around cables under tension preventing entanglement and impact injuries if cable fails. Position barriers or marking tape delineating exclusion zones. Permit only essential pulling and feeding crew within exclusion zones during pulling operations. Workers within zones maintain awareness of cable position and maintain safe distances from cable entry and exit points. Never place hands near conduit entry points while cable is moving. Stop pulling if workers need to cross exclusion zones or adjust equipment.

Implementation

1. Before commencing cable pulling, establish 2-metre exclusion zone around cable path from feeding point through pulling equipment to conduit entry 2. Position barrier tape or safety cones delineating exclusion zone boundaries preventing entry of workers not involved in pulling operation 3. Brief all site personnel on exclusion zones and requirement to stay clear during cable pulling operations 4. Limit personnel within exclusion zone to minimum required - typically pulling operator, feeding operator, and one guide at conduit entry 5. Workers within exclusion zone maintain awareness of cable position and remain clear of direct line between pulling equipment and conduit entry 6. Never place hands within 500mm of conduit entry or exit points while cable is moving under tension 7. Position at side of cable route rather than in direct line with cable path minimising impact risk if cable breaks or whips 8. If workers need to cross exclusion zone or adjust equipment during pulling, stop winch and release tension before crossing 9. Monitor cable condition during pulling - if insulation damage or conductor exposure observed, stop immediately and assess damage 10. After completing pulling operation, remove barriers and brief personnel that area is clear for normal access

Cable Tension Monitoring and Pull Limit Compliance

Administrative Control

Establish procedure ensuring cable pulling tension stays within manufacturer specifications preventing cable damage. Obtain maximum pulling tension limits from cable manufacturer data sheets before commencing pulling. Use winches with integrated load monitoring displaying real-time tension. Calculate maximum permitted tension based on conductor size - typically 50N per mm² for copper conductors. For manual pulling without load monitoring, limit pull length and use multiple pull points breaking long runs into manageable sections. Apply cable pulling lubricant reducing friction in long or complex routes.

Implementation

1. Obtain cable manufacturer data sheets specifying maximum pulling tension before planning cable installation 2. Calculate maximum permitted tension for cables being installed - typically 50N per mm² conductor cross-sectional area 3. For 35mm² single core cable, maximum tension is 1750N (50N × 35mm²); for 185mm² cable, maximum is 9250N 4. Select pulling equipment with load monitoring capability - load cell, dynamometer, or hydraulic pressure gauge 5. Before commencing pull, set tension monitoring alarm at 80% of maximum permitted tension providing warning before limit is reached 6. For manual pulling without load monitoring, limit pull to maximum 30 metres with maximum 2 bends of 90 degrees total 7. Apply cable pulling lubricant to cable before pulling - particularly important for long pulls or multiple bends 8. Monitor tension continuously during pulling - if tension approaches limit, stop pulling and investigate binding cause 9. If tension limit is reached before pull completion, install intermediate pull point breaking pull into shorter sections 10. Document maximum tension reached during pull in installation records for warranty and compliance purposes

Service Location and Underground Hazard Identification

Administrative Control

Conduct comprehensive underground service location before any excavation for cable pit access or duct installation. Obtain service location plans from utility providers including electricity, gas, water, telecommunications, and sewer. Engage qualified service locator using electronic locating equipment to identify buried services. Mark located services using appropriate colour coding. Hand dig trial holes exposing services before mechanical excavation. Maintain minimum clearances from located services during excavation. Assume all services are live unless confirmed isolated.

Implementation

1. Before commencing any excavation, obtain service location information from all utility providers - Dial Before You Dig service provides consolidated response 2. Review service plans identifying all utilities shown in excavation area including electrical, gas, water, telecommunications, and drainage 3. Engage qualified service locator to scan excavation area using electronic locating equipment detecting buried services 4. Mark located services using appropriate colour spray paint - red for electrical, yellow for gas, blue for water, orange for telecommunications 5. Hand dig trial holes at service crossing points exposing services to verify exact depth and location before mechanical excavation 6. Maintain minimum clearances from located services during excavation - 300mm from electrical cables, 500mm from gas pipes 7. Use insulated hand tools within 300mm of located electrical services - no mechanical excavation permitted within clearance distance 8. Assume all electrical services are energised unless confirmed isolated by asset owner and verified with voltage detector 9. If service location plans conflict with electronic location results, excavate conservatively assuming worst-case service position 10. Immediately stop work and notify relevant utility if unexpected service is encountered during excavation

Heat Stress Management for Extended Cable Pulling

Administrative Control

Implement heat stress controls for cable hauling work in hot conditions or confined spaces. Schedule physically demanding cable pulling during cooler morning hours where possible. Implement work-rest cycles allowing recovery from heat exposure. Provide unlimited cold drinking water at work location. Monitor workers for heat stress symptoms. Provide cooling equipment including portable fans and shade structures. Limit continuous work in confined pits to 20-30 minutes followed by cool-down breaks in air-conditioned area or shade.

Implementation

1. Monitor weather forecasts before scheduling cable hauling work - reschedule heavy pulls to cooler days if outdoor temperature will exceed 35°C 2. Schedule physically demanding cable pulling during morning hours before peak temperature occurs 3. Implement 50 minutes work / 10 minutes rest cycle during hot conditions allowing recovery from heat exposure 4. Position insulated water containers at work location providing unlimited cold drinking water - minimum 1 litre per worker per hour 5. Brief workers on heat stress symptoms including heavy sweating followed by dry skin, confusion, weakness, and rapid heart rate 6. Assign supervisor to monitor workers for heat stress symptoms with authority to stop work if symptoms observed 7. For confined pit work in hot conditions, limit continuous time in pit to maximum 20 minutes followed by 10 minutes in cool area 8. Provide portable cooling fans at pit openings improving ventilation and air movement for confined space workers 9. Establish shaded rest area or air-conditioned vehicle for worker cool-down breaks 10. If worker shows heat stress symptoms, move to cool area, provide water, apply cooling to head and neck, and seek medical attention

Personal Protective Equipment for Cable Hauling

Personal Protective Equipment

Provide PPE addressing manual handling, entanglement, electrical contact, and confined space hazards. Close-fitting clothing without loose cuffs prevents entanglement in cable or rotating drums. Cut-resistant gloves protect hands during cable handling. Hearing protection for winch operation. Confined space full-body harness for pit entry enabling emergency retrieval. Safety glasses for overhead work in ceiling spaces. Electrical-rated gloves if working near energised equipment.

Implementation

1. Issue close-fitting work clothing without loose cuffs, pockets, or hanging elements that could catch on moving cable 2. Provide cut-resistant gloves rated to Level 3 per AS/NZS 2161.4 for handling cable with sharp wire armour or rough surfaces 3. Issue safety glasses with side shields rated to AS/NZS 1337 for overhead cable installation in ceiling spaces 4. Supply full-body harness conforming to AS/NZS 1891.1 for confined space entry - attach to retrieval system for emergency rescue 5. Provide Class 3 hearing protection per AS/NZS 1270 for workers operating or working near cable winches 6. Issue steel cap safety boots rated to AS/NZS 2210.3 protecting against dropped cable drums, tools, and equipment 7. For work near energised electrical equipment, provide insulated electrical gloves rated to Class 0 (1000V) per AS/NZS 2225 8. Supply high-visibility vests for cable hauling work in areas with vehicle or mobile plant traffic 9. Ensure all PPE is maintained in serviceable condition - inspect before each use and replace when damaged 10. Train workers on correct PPE selection for specific cable hauling tasks and proper use

Personal protective equipment

Requirement: Level 3 cut resistance per AS/NZS 2161.4

When: During all cable handling operations including feeding cable, guiding cable through conduit entries, and managing cable drums

Requirement: Medium impact rated per AS/NZS 1337

When: During overhead cable installation in ceiling spaces and when working beneath cable trays or elevated conduit systems

Requirement: Harness per AS/NZS 1891.1 with dorsal D-ring

When: When entering cable pits or manholes for cable feeding, pulling equipment setup, or cable laying operations

Requirement: Category 1 impact protection per AS/NZS 2210.3

When: Throughout all cable hauling work to protect against dropped cable drums, heavy cable reels, and hand tools

Requirement: Class 3 protection per AS/NZS 1270

When: When operating cable pulling winches or working within 5 metres of operating mechanical pulling equipment

Requirement: Class D day/night per AS/NZS 1906.4

When: When performing cable hauling work in areas with vehicle traffic, mobile plant operation, or public access

Requirement: No loose cuffs, pockets, or hanging elements

When: Throughout all cable hauling operations particularly near moving cable and rotating cable drums

Inspections & checks

Before work starts

  • Verify cable route is clear and accessible from cable drum location through entire conduit system to cable termination point
  • Inspect conduit system for blockages, sharp edges, misalignment, or damage requiring rectification before cable pulling
  • Check cable drum condition including structural integrity, rotation bearing condition, and drum flange security
  • Inspect pulling equipment including winch operation, load monitoring function, cable grips, and anchorage points
  • Test communication equipment including two-way radios between pulling and feeding positions ensuring clear communication
  • Verify cable specifications match installation requirements including conductor size, insulation type, and voltage rating
  • For confined space entry, test atmosphere measuring oxygen content, flammable gases, and toxic gases before entry
  • Check availability of emergency equipment including first aid kit, retrieval equipment for confined space, and emergency contacts
  • Conduct service location for underground cable routes including utility plans and electronic service location scanning
  • Brief all cable pulling crew on pulling sequence, communication protocol, force limits, and emergency procedures

During work

  • Monitor cable pulling tension using winch load monitoring ensuring tension stays within cable manufacturer specifications
  • Maintain continuous communication between pulling and feeding positions coordinating pulling speed with feeding rate
  • Check cable condition during pulling watching for insulation damage, conductor exposure, or signs of over-tension
  • Monitor workers for heat stress symptoms during extended cable pulling operations particularly in hot conditions
  • Verify exclusion zones around cable under tension are maintained with only essential personnel within hazard area
  • For confined space work, maintain continuous atmospheric monitoring and ventilation verifying safe conditions
  • Check cable drum rotation is smooth and controlled preventing cable twisting or tangling during feeding
  • Monitor cable entry into conduit system ensuring cable feeds smoothly without binding or catching on conduit edges
  • Verify workers maintain safe distances from moving cable and do not place hands near entry or exit points
  • Stop pulling operations immediately if tension limits are approached, communication is lost, or binding occurs

After work

  • Inspect pulled cable for damage including insulation cuts, conductor exposure, or signs of over-tension requiring investigation
  • Verify cable is properly secured at termination points with adequate slack for final connections and future maintenance
  • Check cable identification labelling is installed at accessible points including pit entries, junction boxes, and termination panels
  • Clean cable route removing temporary pulling equipment, cable drum remains, and packaging materials
  • Complete cable installation records documenting cable type, length installed, route, maximum pulling tension, and installation date
  • For underground installations, photograph cable layout in pits before backfilling providing as-built documentation
  • Test cable insulation resistance using insulation tester verifying cable was not damaged during installation
  • Secure cable pit lids and covers restoring access points to safe condition preventing falls
  • Complete confined space entry logs documenting atmospheric test results, entry times, and worker names for compliance records
  • Debrief cable pulling crew on lessons learned, difficulties encountered, and improvements for future cable installations

Step-by-step work procedure

Give supervisors and crews a clear, auditable sequence for the task.

Field ready

Cable Route Preparation and Inspection

Inspect complete cable route before commencing pulling operations. Walk entire route from cable drum position through conduit system to termination point identifying potential problems. Check conduit entries for sharp edges, misalignment, or damage. Verify conduit is clear by pushing test mandrel or draw wire through system. For underground duct installations, inspect pits and manholes for water accumulation, debris, or structural damage. Remove blockages using high-pressure water jetting, rodders, or manual clearing. Check that cable drum delivery position allows clear sight line for cable feeding and adequate space for drum rotation. Position cable drum on jack stands or drum roller allowing controlled rotation during feeding. Verify pulling equipment location provides straight pull line into conduit entry minimising cable bending. Install temporary conduit bushing or edge protection at conduit entry point preventing cable insulation damage during pulling. For ceiling space installations, verify ceiling access points are adequate and ceiling structure can support cable weight.

Safety considerations

Conduct service location before any excavation for pit access. Test atmosphere in confined pits before entry. Ensure adequate lighting in inspection areas. Wear safety glasses when inspecting overhead conduit routes. Check for overhead power lines near cable drum position or pulling equipment setup areas.

Pulling Equipment Setup and Testing

Position cable pulling winch at pulling end with secure anchorage to structural elements capable of resisting maximum pulling force. For 35mm² cable, maximum tension may approach 1750N requiring anchorage to substantial structural members or ground anchors. Install winch power supply ensuring adequate cable length and appropriate circuit protection. Test winch operation verifying forward and reverse function, speed control, and emergency stop. Calibrate or verify calibration of winch load monitoring system. Set tension monitoring alarm at 80% of cable maximum pulling tension. Install cable grip or pulling eye on cable end following manufacturer instructions. Pulling eyes provide better load distribution than grips for long heavy pulls. Attach pulling line from winch to cable grip ensuring secure connection using appropriate shackles or connectors. Position guide rollers at conduit entry point supporting cable at correct angle preventing sharp bending. Establish communication system between winch operator and feeding crew using two-way radios programmed to dedicated channel. Test communication system verifying clear audio in both directions.

Safety considerations

Verify winch anchorage is secure before applying tension. Position winch operator at safe distance from cable path with clear view of cable entry. Ensure exclusion zones are established around equipment. Check all connections are secure using appropriate safety factors. Never stand in direct line with cable under tension.

Cable Feeding Position Setup

Position cable drum at feeding end allowing cable to pay off from top of drum preventing cable twist during pulling. Install drum jack stands or powered drum rollers supporting full drum weight. For large drums exceeding 500kg, use mechanical drum rollers with adjustable braking maintaining controlled rotation speed. Position feeding crew allowing clear view of drum rotation and cable pay-off point. One crew member manages drum rotation controlling brake or rotation speed matching pulling rate. Second crew member guides cable from drum toward conduit entry preventing tangles and ensuring smooth pay-off. For underground installations requiring confined space entry, establish confined space procedures including atmospheric testing, forced ventilation, standby person, and retrieval equipment before entering pits. Apply cable pulling lubricant to cable at feeding point reducing friction in conduit system. Use manufacturer-recommended lubricant compatible with cable insulation type. Apply lubricant liberally but avoid excessive application that creates slipping hazard.

Safety considerations

Secure cable drum preventing rolling or tipping. Position workers clear of drum rotation plane preventing entanglement if drum rotates rapidly. For confined space entry, follow formal entry procedures including atmospheric testing and continuous monitoring. Maintain communication with pulling crew at all times. Position clear of direct cable path between drum and conduit entry.

Cable Pulling Operation and Monitoring

Begin cable pulling using slow controlled winch speed establishing smooth cable movement through conduit system. Feeding crew matches drum rotation to pulling rate preventing excessive slack or tension spikes. Monitor winch load indication continuously watching for tension approaching alarm setpoint. Typical pulling tension for 35mm² single core cable through 50 metres of conduit with two 90-degree bends is 800-1200N. If tension approaches maximum limits, stop pulling and investigate binding cause. Common binding causes include conduit misalignment, blockages, inadequate lubrication, or cable jacket catching on conduit joints. Maintain constant communication between winch operator and feeding crew. Feeding crew reports drum rotation rate, cable condition, and any problems observed. Winch operator reports pulling tension, speed, and cable movement. If communication is lost, immediately stop pulling until communication is restored. Guide cable at conduit entry point ensuring smooth entry without catching on bushing or conduit edge. Never place hands within 500mm of moving cable or conduit entry point. Stop pulling if cable shows signs of damage including insulation tears, conductor exposure, or jacket distortion.

Safety considerations

Monitor tension continuously staying within safe limits. Maintain exclusion zones around cable under tension. Position at side of cable path not in direct line. Stop immediately if binding occurs or communication is lost. Watch for heat buildup in cable from friction. Never override tension alarms or limits.

Cable Securing and Installation Completion

Once cable pulling is complete with required length pulled through conduit system, slowly release winch tension and disconnect pulling grip or eye. Secure cable at both ends using temporary cable ties or supports preventing cable from retracting into conduit. At termination points, provide adequate cable slack for final connections and future maintenance access. Calculate service loop length based on equipment requirements typically 1 to 1.5 metres at switchboard terminations. Cut cable to length using appropriate cable cutters sized for conductor being cut. Install cable identification labels at accessible points including pit entries, junction boxes, ceiling access points, and termination panels. Use durable weatherproof labels for outdoor or underground locations. Document cable installation including cable type, route description, length installed, date, and maximum pulling tension reached. For underground installations, photograph cable layout in pits showing cable position, support, and routing before backfilling. These photos provide valuable as-built documentation for future maintenance. Test cable insulation resistance using insulation resistance tester applying 500V test voltage between conductors and between conductors and earth. Minimum acceptable reading is 1 megohm with higher values indicating cable was not damaged during installation.

Safety considerations

Release tension slowly preventing sudden cable movement. Secure cable before disconnecting pulling equipment. Wear cut-resistant gloves when cutting cable. Verify cable is not energised before testing insulation resistance. For underground installations, secure pit lids preventing falls after cable installation. Clean work area removing trip hazards.

Frequently asked questions

What maximum pulling force can workers safely apply manually pulling cables without mechanical assistance?

Manual cable pulling should be limited to forces not exceeding 250 Newtons (approximately 25 kilograms force) sustained over pulling duration. Even at this level, pulls should not exceed 30 metres distance or involve more than two 90-degree bends totalling 180 degrees of direction change. Beyond these limits, mechanical pulling using winches becomes necessary to prevent manual handling injuries. Calculate estimated pulling force before commencing work based on cable weight, conduit friction, and bends in route. Cable manufacturers provide pulling tension calculators or charts estimating force requirements. For 4mm² cable through 20 metres of conduit with one 90-degree bend, pulling force is approximately 150N well within manual pulling capability. For 16mm² cable through 40 metres with three bends, estimated force exceeds 500N requiring mechanical pulling. Apply cable pulling lubricant significantly reducing friction particularly for long pulls through multiple bends. Lubricant can reduce pulling force by 30-50% compared to dry pulling. Use team pulling for forces approaching manual limits with workers coordinating effort through communication. Position workers to apply steady pulling force maintaining straight posture with force applied through legs rather than back. Never jerk or apply impact loads which create force spikes damaging cable and injuring workers.

How do I prevent cable damage from exceeding maximum pulling tension limits?

Prevent cable damage by implementing multiple controls working together. First, obtain cable manufacturer maximum pulling tension specifications before planning installation - typically 50N per mm² of conductor cross-sectional area for copper conductors. For 35mm² cable, maximum is 1750N; for 95mm² cable, maximum is 4750N. Second, use cable winches incorporating load cells or tension monitoring displaying real-time pulling force. Set alarm at 80% of maximum permitted tension providing warning before damage occurs. Third, calculate estimated pulling force before commencing work based on cable weight, conduit friction coefficient, and bends in route using cable manufacturer calculation methods. If estimated force approaches limits, redesign route to reduce bends or install intermediate pull points breaking pull into shorter sections. Fourth, apply cable pulling lubricant liberally reducing friction between cable and conduit - lubricant reduces pulling force 30-50% particularly important for long pulls. Fifth, ensure conduit system is properly aligned without offset joints, sharp edges, or blockages causing binding and excessive friction. Sixth, monitor cable condition during pulling watching for signs of over-tension including insulation stretching, conductor exposure, or jacket distortion. Stop immediately if damage is observed. Seventh, for multi-conductor cables, use proper pulling grips distributing tension across cable structure rather than pulling on conductors directly. Eighth, never exceed winch speed recommendations as excessive speed increases friction and tension. Maintain steady controlled pulling speed matching feeding rate from drum.

What confined space procedures are required for cable hauling work in electrical pits and manholes?

Confined space procedures for cable pit entry include multiple mandatory controls. First, identify all pits and manholes as confined spaces requiring formal entry procedures - pits deeper than 1.2 metres with restricted access are confined spaces under WHS regulations. Second, conduct atmospheric testing before entry using calibrated gas detector measuring oxygen content must exceed 19.5 percent, flammable gas must be zero, and toxic gases must be below exposure limits. Third, provide continuous mechanical ventilation using portable blower positioned at pit opening forcing fresh air into space - maintain ventilation throughout occupation period. Fourth, issue personal gas detector to each worker entering pit with alarms set for oxygen depletion below 19.5%, flammable gas above 10% LEL, and relevant toxic gases. Fifth, position trained standby person at pit opening who does not enter space but maintains constant communication with entrant. Standby person must not enter for rescue but summons trained rescue team. Sixth, provide emergency retrieval equipment including tripod and winch, rescue harness worn by entrant, and retrieval line attached to entrant's harness dorsal D-ring. Seventh, establish communication protocol requiring entrant to respond to standby person checks every 5 minutes - failure to respond triggers rescue procedures. Eighth, limit continuous time in confined pit to 30 minutes particularly in hot conditions before rotating workers to fresh air break. Ninth, brief all workers on entry procedure, communication requirements, hazards, and emergency procedures including rescue. Never enter confined space without implementing these procedures - numerous fatalities have resulted from uncontrolled confined space entry.

How do I coordinate cable pulling between feeding and pulling crews when visual contact is impossible?

Coordination between separated pulling and feeding crews requires reliable communication system and clear protocols. Use two-way radios programmed to dedicated channel eliminating interference from other site communications. Test radios before commencing pulling verifying clear audio in both directions and adequate battery charge for pulling duration. Establish communication protocol including standard phrases and response requirements. Typical protocol: winch operator announces "Ready to pull" and waits for feeding crew response "Ready to feed" before starting. Winch operator announces "Starting pull" before applying tension. During pulling, maintain open communication with feeding crew reporting drum rotation status and any problems observed. Winch operator reports pulling tension and speed adjusting to match feeding rate. If feeding crew reports drum not rotating smoothly or cable tangling, winch operator immediately stops pull. Establish emergency stop procedure where either crew can call "Stop pull" and other crew immediately stops operations. If communication is lost during pulling, immediately stop pulling operation and do not resume until communication is restored. For very long cable runs where radio communication may be unreliable, position intermediate crew member at midpoint relaying communications between ends. Never attempt cable pulling when communication cannot be maintained - risk of over-tensioning cable or entrapping workers requires continuous coordination. For critical or complex pulls, conduct pre-pull briefing bringing pulling and feeding crews together to discuss sequence, communication protocol, tension limits, and emergency procedures. Practice communication protocol during equipment setup verifying all crew members understand and can execute procedures.

What service location procedures must I follow before excavating for cable pit access?

Service location before excavation requires systematic approach ensuring all buried services are identified. First, contact Dial Before You Dig (1100) minimum 2 business days before planned excavation providing location details and work description. Utility owners respond with service location plans showing underground assets in work area including electricity, gas, water, telecommunications, and sewer services. Second, review service plans from all responding utilities noting services shown crossing or adjacent to proposed excavation. Plans indicate approximate service locations but may not show exact depth or position particularly for older services. Third, engage qualified service locator to scan excavation area using electronic locating equipment capable of detecting electrical cables, telecommunications cables, metallic pipes, and some non-metallic services. Locators mark detected services using temporary spray paint following national colour code - red for electrical, yellow for gas, blue for water, orange for telecommunications. Fourth, hand dig trial holes at service crossing points exposing services to verify exact depth and horizontal position before commencing mechanical excavation. Trial holes must be excavated using hand tools within 500mm of indicated service location. Fifth, maintain minimum clearance distances from exposed services - 300mm from electrical cables and gas pipes, machinery prohibited within clearance zone. Use hand tools only for excavation within clearance distances. Sixth, assume all electrical services are energised unless confirmed isolated by asset owner and tested dead with voltage detector. Never rely on service age or visual appearance to judge energisation status. If unexpected service is discovered during excavation, immediately stop work and notify relevant utility before proceeding. Document service location activities including plans obtained, locating performed, and services found providing protection from liability if unidentified service is subsequently damaged.

How should I manage heat stress during extended cable pulling operations in hot conditions?

Heat stress management for cable pulling requires proactive controls particularly during Australian summer when outdoor temperatures exceed 35 degrees Celsius or when working in confined pits. First, schedule physically demanding cable pulling during cooler morning hours before 11am when temperatures are lowest. Delay afternoon work if temperature exceeds 38 degrees Celsius and work can be rescheduled. Second, implement structured work-rest cycles allowing physiological recovery from heat exposure. Use 50 minutes work / 10 minutes rest cycle in moderate heat, reducing to 30 minutes work / 15 minutes rest when temperature exceeds 35 degrees Celsius or when working in confined spaces exceeding 40 degrees Celsius. Third, provide unlimited cold drinking water at work location in insulated containers maintaining water temperature below 15 degrees Celsius. Workers should consume minimum 200ml water every 15 minutes regardless of thirst sensation. Fourth, establish shaded rest area or air-conditioned vehicle allowing workers to cool down during rest breaks. Rest breaks in ambient heat provide little recovery benefit. Fifth, for confined pit work, limit continuous time in pit to maximum 20 minutes in hot conditions before mandatory rotation to fresh air. Position portable cooling fans at pit openings improving air movement for workers in pits. Sixth, assign supervisor to monitor workers for heat stress symptoms including heavy sweating progressing to dry skin, confusion, weakness, rapid heart rate, and loss of coordination. These symptoms indicate developing heat stroke requiring immediate medical attention. Seventh, allow workers to self-pace work intensity in extreme heat - some loss of productivity is acceptable to prevent heat-related illness. Eighth, provide cooling equipment including ice vests, cooling towels, or misting fans for workers in extreme conditions. Workers wearing full PPE including long sleeves and gloves face additional heat stress requiring enhanced controls. Never ignore heat stress symptoms or pressure workers to continue in unsafe conditions - heat stroke can cause permanent organ damage and death within 30-60 minutes if untreated.
