Tyre changing operations on heavy vehicles, earthmoving equipment, and mobile plant involve servicing large high-pressure tyres weighing hundreds of kilograms on equipment including excavators, loaders, dump trucks, graders, and other construction machinery. These operations expose workers to catastrophic stored energy hazards from compressed air in tyres and split rim assemblies, severe manual handling risks from heavy tyre and wheel components, and equipment positioning hazards when vehicles must be jacked or supported during wheel removal. Safe tyre changing requires comprehensive understanding of tyre construction types, split rim explosion hazards, proper inflation procedures using safety cages, and Australian Standards compliance to protect workers from the fatal and devastating injuries that occur when tyre service procedures fail.

Unlimited drafts • Built-in WHS compliance • Works across every Australian state

Overview

What this SWMS covers

Tyre changing operations on heavy vehicles, earthmoving equipment, and mobile plant involve servicing large high-pressure tyres weighing hundreds of kilograms on equipment including excavators, loaders, dump trucks, graders, and other construction machinery. These operations expose workers to catastrophic stored energy hazards from compressed air in tyres and split rim assemblies, severe manual handling risks from heavy tyre and wheel components, and equipment positioning hazards when vehicles must be jacked or supported during wheel removal. Safe tyre changing requires comprehensive understanding of tyre construction types, split rim explosion hazards, proper inflation procedures using safety cages, and Australian Standards compliance to protect workers from the fatal and devastating injuries that occur when tyre service procedures fail. Heavy vehicle and earthmoving equipment tyres differ fundamentally from light vehicle tyres in both construction and servicing requirements, with many heavy equipment tyres using multi-piece rim assemblies (split rims or lock ring rims) that present unique explosion hazards not present in single-piece rim configurations.

Fully editable, audit-ready, and aligned to Australian WHS standards.

Why this SWMS matters

Tyre changing operations on heavy vehicles and earthmoving equipment have caused numerous fatalities and catastrophic injuries across Australian workplaces, with split rim explosions being particularly devastating incidents where workers are killed instantly by rim components projected at extreme velocities during improper inflation procedures. Resources Safety & Health Queensland and other Australian safety regulators document multiple fatal incidents where lack of safety cage use, improper rim assembly, or inadequate deflation verification before dismounting caused explosive rim separation. From a regulatory compliance perspective, tyre changing operations must comply with Australian Standard AS 4457.1:2007 and AS 4457.2:2008, which specify mandatory requirements for safety cage use, deflation verification, component inspection, and personnel competency. These standards represent the baseline for compliance with general WHS duties requiring elimination or minimisation of risks associated with stored energy hazards.

Reinforce licensing, insurance, and regulator expectations for Tyre Changing Heavy Vehicles Safe Work Method Statement crews before they mobilise.

Hazard identification

Surface the critical risks tied to this work scope and communicate them to every worker.

Risk register

Explosive Rim Separation During Inflation (Split Rim Explosion)

high

Multi-piece rim assemblies used on many heavy vehicles and earthmoving equipment can explosively separate during tyre inflation if rim components are improperly seated, damaged, or corroded, projecting heavy metal components at extreme velocities capable of causing instant fatality to anyone within 10-15 metres. Split rim assemblies include side rings and lock rings that mechanically interlock when properly assembled, with air pressure forcing components against rim base creating secure assembly. However, if side rings or lock rings are not fully seated in rim grooves during initial inflation, increasing air pressure can cause sudden violent separation where rings are launched as projectiles with kinetic energy equivalent to explosive fragmentation. Lock ring rims feature spring-loaded lock rings that snap into rim grooves under tension—improper installation or damaged rim grooves can allow lock rings to dislodge during inflation causing explosive release. Even tyres on single-piece rims can cause catastrophic incidents if inflated while tyre beads are not properly seated on rim flanges, with sudden bead seating creating violent tyre movement. The explosion occurs suddenly without warning when sufficient pressure accumulates to overcome mechanical resistance, typically at 100-400 kPa (15-60 psi) well below full working pressure. Workers positioned adjacent to tyres during inflation are struck by projected rim components or violently displaced tyres, sustaining fatal head and torso trauma, severe crush injuries, or being thrown against structures or equipment. The extreme forces involved in rim explosions make these incidents virtually unsurvivable for workers positioned near inflating tyres without protective shielding. Historical incidents include multiple Australian fatalities where workers inflated split rim assemblies outside safety cages, with rim components penetrating vehicle bodies, workshop walls, and steel structures demonstrating enormous energy release.

Consequence: Fatal injuries to workers struck by explosively separated rim components or tyres during unprotected inflation, catastrophic head and torso trauma causing instant death or permanent severe disability, multiple casualties when rim component projectiles strike workers positioned up to 15 metres from inflation location, and serious property damage to workshops, vehicles, and equipment from explosive forces penetrating structures and creating secondary projectile hazards.

Manual Handling Injuries from Heavy Tyre and Wheel Components

high

Heavy vehicle and earthmoving equipment tyres, wheels, and rim components create extreme manual handling hazards with masses ranging from 50-1,000 kilograms for individual components, exceeding safe manual lifting limits and requiring mechanical handling equipment for safe movement. A complete wheel assembly including tyre, rim, and remaining air pressure can weigh 300-800 kilograms for typical construction equipment, with larger mining equipment assemblies exceeding 1,500-5,000 kilograms. Individual dismounted tyres weigh 100-500 kilograms, multi-piece rim bases weigh 50-300 kilograms, and side rings or lock rings weigh 10-50 kilograms. Manual lifting or moving these components causes acute back injuries from sudden overload, chronic degenerative back conditions from repeated heavy lifting over time, crushed hands or feet when components are dropped or slip during manual handling, and fatigue injuries when workers persist in manual handling beyond physical capacity. Awkward lifting positions required when accessing wheels on equipment—including crouching positions, reaching under vehicle frames, or working on uneven ground—compound manual handling risks by adding postural stress to weight load. Two or three-person team lifting distributes loads but creates coordination challenges where timing errors cause some workers to bear excessive load share or where communication failures result in sudden uncontrolled load movements. Rolling tyres appears safer than lifting, but tyres weighing several hundred kilograms develop considerable momentum that workers cannot control on sloped ground, causing runaway tyres that strike workers, vehicles, or structures. Some workers improvise mechanical aids including vehicle-mounted chains, rope slings, or forklift tynes to lift heavy components, but these improvised approaches lack proper engineered lifting points and load-rated rigging, creating dropped load risks from rigging failures or loss of load control.

Consequence: Acute lumbar spine injuries requiring surgical intervention and extended recovery periods preventing work, chronic degenerative disc conditions causing permanent reduced capacity and ongoing pain, crushed or amputated fingers and toes from dropped rim components weighing tens of kilograms, shoulder and upper limb injuries from excessive forces during team lifting, and workers' compensation claims for permanent disabilities from accumulated manual handling strain over multiple incidents.

Stored Energy Release from Inadequately Deflated Tyres

high

Residual air pressure remaining in tyres during rim disassembly operations causes explosive energy release when rim components are forcefully separated before complete deflation, projecting rim rings, tyre beads, or entire rim assemblies causing fatal injuries or crushing workers between tyre and vehicle components. Tyres that appear deflated based on visual observation or initial air release from valve stems may retain 50-200 kPa (7-30 psi) residual pressure sufficient to cause violent rim separation when side rings or lock rings are loosened. Tyre beads wedged against rim flanges trap air pockets preventing complete deflation through valve stems, requiring bead breaking procedures to release trapped air before rim disassembly. Dual tyre configurations (two tyres mounted on common hub) present particular hazard where pressure in one tyre can migrate to second tyre through valve connections or can cause second tyre to explosively expand when first tyre is removed releasing pressure differential. Tubeless tyres with damaged or corroded valve cores may not deflate through normal valve operation, requiring alternative deflation methods including valve core removal or drilling drainage holes in sidewalls well away from rim assemblies. Workers using hammers and drifts to disassemble rim components from partially deflated tyres apply impact forces that overcome mechanical interference between components, triggering sudden uncontrolled separation and component projection. The temptation to begin disassembly while residual pressure remains arises from perception that 'low' pressure is safe, from inadequate deflation tools making full deflation time-consuming, or from production pressure to minimise service downtime encouraging workers to commence work before complete safe deflation is verified.

Consequence: Fatal injuries when workers are struck by rim components explosively projected during disassembly of inadequately deflated assemblies, serious crushing injuries when workers are trapped between expanding tyres and vehicle structures during controlled deflation failures, impact injuries from rim components or tools rebounding from sudden energy release striking workers in head or torso, and environmental release of tyre service fluids contaminating ground when tyres rupture during uncontrolled energy release.

Vehicle Instability During Wheel Removal and Installation

medium

Heavy vehicles and earthmoving equipment positioned on jacks, axle stands, or other supports for wheel removal create instability hazards where inadequate support, support failure, or ground subsidence causes vehicle collapse crushing workers positioned beneath or adjacent to equipment during tyre service. Vehicles must be raised to enable wheel removal and installation, with raising height depending on wheel diameter and available clearance for rolling wheel assemblies from beneath vehicles. Vehicle stability during raising and while raised depends on support capacity, support positioning under strong vehicle structural points, ground bearing capacity beneath supports, and prevention of vehicle movement during work. Mobile equipment including excavators and loaders features articulated frames, hydraulically-positioned booms or buckets, and load-shifting capabilities creating dynamic stability challenges beyond simple static mass considerations. Inadequate jacking procedures including positioning single jack under weak structural points, using undersized jacks for vehicle mass, or raising vehicles on soft ground causing jack subsidence create collapse risks. Once raised, vehicles supported only on hydraulic jacks are inherently unstable as hydraulic seals can leak causing slow height loss, or jack pistons can suddenly fail from overload or side loading. Axle stands (jack stands) provide more reliable raised vehicle support when correctly positioned under strong structural points and secured on firm level ground, but inappropriate stands lacking adequate capacity or workers positioning stands under weak structural points can cause collapse. Vehicle movement during tyre service from accidental transmission engagement, parking brake release, or external impacts from equipment movements creates vehicle displacement from supports. Some workers position themselves partially or fully beneath raised vehicles to access wheel mounting bolts, placing themselves in highest-risk position if vehicle collapse occurs. Wind loading on large equipment with high surface area can create forces causing vehicle rocking or movement when raised on narrow support points.

Consequence: Fatal crushing injuries when workers positioned beneath or adjacent to vehicles are trapped under collapsing equipment weighing tens of tonnes, serious trauma from partial vehicle collapse pinning workers' limbs or torso against ground or equipment, equipment damage from uncontrolled collapse causing structural deformation or component damage requiring major repairs beyond tyre service requirements, and secondary injuries when vehicle collapse causes workers to fall from elevated working positions or strikes workers with displaced components.

Tyre Bead Seating Failures and Sudden Tyre Movement

medium

Tyre beads that do not smoothly seat on rim flanges during initial inflation can suddenly shift or 'pop' into seated position causing violent lateral tyre movement, projecting tyres sideways or upward striking workers or structures adjacent to inflation locations. Tubeless tyres require airtight seal between tyre bead and rim flange to maintain inflation—achieving initial seal requires forcing tyre beads outward against rim flanges through rapid air volume delivery creating mechanical interference. When beads are not concentrically positioned on rims before inflation, one section may seat while others remain unseated, creating asymmetric internal pressure distribution that suddenly equalises when remaining bead sections pop into place. This sudden bead seating releases stored pressure energy as kinetic energy causing tyre to lurch sideways by 100-300mm, striking any workers, tools, or structures positioned immediately adjacent. Inflation with workers standing over tyres or crouching beside tyres places them directly in tyre movement path. Corroded or damaged rim flanges provide irregular bead seating surfaces causing localized unseated areas requiring higher pressures to force seating, increasing violent movement magnitude when seating eventually occurs. Lubricant application on tyre beads and rim flanges facilitates smoother seating but creates messy slippery surfaces during tyre handling. Inadequate initial inflation pressure application causes gradual bead seating without violent movement, but workers impatient for bead seating may increase inflation rate or pressure beyond recommendations attempting to accelerate seating. Some workers use flammable liquids including ether or petrol to create explosive mixture inside tyres for 'explosion seating' forcing beads outward—this extremely dangerous practice causes fires, explosions, and uncontrolled tyre movements far exceeding controlled seating forces and is strictly prohibited by Australian Standards and workplace procedures.

Consequence: Serious impact injuries when workers are struck by suddenly moving tyres during bead seating, causing broken bones, head trauma, or crushing injuries against structures, minor injuries from workers losing balance and falling when startled by sudden tyre movement, damage to tyre service equipment and surrounding facilities from displaced tyres striking structures or equipment, and fire or explosion incidents when workers use flammable liquids for bead seating causing burns and property damage.

Rim Component Deterioration and Structural Failure

medium

Multi-piece rim assemblies subjected to corrosion, mechanical damage, or fatigue cracking develop structural weaknesses that can cause sudden component failure during inflation or service, creating rim explosion risks or sudden air pressure loss causing uncontrolled equipment movement. Split rim components including rim bases, side rings, and lock rings are manufactured from steel subject to environmental corrosion from exposure to moisture, road salt, and corrosive materials handled by equipment. Surface corrosion appears as rust scaling, pitting, or metal loss particularly in rim grooves where lock rings seat and in areas where moisture accumulates. Corrosion reduces metal thickness weakening mechanical strength and creates irregular surfaces preventing proper component seating. Impact damage from rim contact with rocks, kerbs, excavation edges, or other equipment causes dents, cracks, or deformation affecting rim integrity and component assembly. Lock ring grooves damaged by corrosion or impact may not fully retain lock rings allowing rings to dislodge during use. Fatigue cracking develops in highly stressed rim areas after extended service life, typically originating from stress concentration points including bolt holes, sharp geometry transitions, or pre-existing surface damage. Cracks may not be visible during cursory inspection particularly when covered by dirt, rust, or paint. Many rim failures occur during inflation when internal pressure loading reveals pre-existing damage that was not apparent during deflated visual inspection. Some operators continue using rims with obvious damage including visible cracks or severe corrosion believing partial damage does not affect safety, when in reality any rim structural compromise creates explosion risk. Inadequate rim inspection procedures focusing only on obvious severe damage miss developing corrosion, minor cracks, or component wear indicating replacement is required before failure occurs. Mixing incompatible rim components from different manufacturers or using incorrect component sizes for specific rim types causes improper assembly where components appear to fit but lack proper mechanical security.

Consequence: Sudden rim failure during inflation or operation causing explosive energy release equivalent to split rim explosion incidents with fatal injury potential, rapid tyre deflation from rim failures during equipment operation causing loss of vehicle control and collision or rollover incidents, equipment damage from rim component failures during operation requiring replacement of damaged wheels, suspension, and vehicle structures, and productivity loss when failed rims require emergency replacement and equipment investigation determining failure cause.

Control measures

Deploy layered controls aligned to the hierarchy of hazard management.

Implementation guide

Mandatory Safety Cage Use for All Tyre Inflation Operations

Engineering

Implement absolute requirement for conducting all heavy vehicle and earthmoving equipment tyre inflation operations within engineered safety cages designed, constructed, and tested to contain explosive rim separation energy and prevent worker exposure to projected rim components. Safety cages provide physical barrier between inflating tyre and workers, designed to withstand impact forces from explosive rim failure without penetration or significant deformation. AS 4457.1:2007 specifies minimum safety cage design requirements including structural strength to contain 200 kilograms mass travelling at 10 metres per second (typical rim component projection velocity), cage construction from minimum 10mm thick steel or equivalent strength materials, three sides of enclosure with open rear for tyre insertion, and opening height sufficient for tyre sizes being serviced. Commercial engineered safety cages meeting Australian Standards are available from industrial safety equipment suppliers, typically costing $5,000-15,000 depending on capacity and features including built-in inflation equipment, lighting, and remote inflation capability. Alternatively, site-fabricated cages designed by qualified engineers can be constructed using structural steel components, though must be load-tested to verify containment capability before operational use. Cage interior should be visible to operators enabling observation of tyre during inflation watching for bead seating without requiring entry into hazard zone. Remote inflation capability using extended air lines with regulators and gauges positioned outside cage enables complete inflation cycle from safe position, with operator able to observe through cage mesh or windows without exposure. Prohibition against any inflation outside safety cages must be absolute regardless of tyre size, pressure level, or worker experience—'just quickly putting some air in' without cage use is precisely the scenario causing fatal incidents when what appears to be routine inflation triggers unexpected rim failure.

Implementation

1. Procure or construct engineered safety cages meeting AS 4457.1:2007 minimum requirements, sized appropriately for largest tyre sizes serviced in fleet, with engineering certification documenting load testing verification 2. Position safety cages in designated tyre service areas with adequate clear space around cages enabling safe tyre insertion and surrounding area evacuation if explosion occurs 3. Equip cages with remote inflation capability using extended high-pressure air lines with regulators mounted outside cage, enabling complete inflation without worker entry 4. Install pressure gauges and inflation control valves outside cage in protected positions enabling operator to monitor and control inflation from safe location with visual observation of tyre through cage openings 5. Establish absolute procedural requirement prohibiting any tyre inflation outside safety cage, communicated through training, signage, and workplace observation with immediate corrective action for violations 6. Mount high-visibility warning signage on cages stating 'DANGER - Tyre Inflation - Stay Clear - Explosive Rim Separation Risk' alerting all personnel to hazard 7. Conduct periodic inspection of safety cage structural integrity examining welds, mesh integrity, door operation, and support structure confirming no deterioration affecting containment capability 8. Train all tyre service personnel in mandatory safety cage use emphasising that cage is primary control preventing fatalities, with fatal consequences when workers elect to bypass cage for convenience or time saving

Complete Tyre Deflation Verification Before Rim Disassembly

Administrative

Establish mandatory tyre deflation verification procedures ensuring zero residual air pressure remains in tyres before commencing rim disassembly operations, eliminating stored energy hazards that cause explosive rim separation during dismounting. Deflation procedures commence with valve core removal using valve core tool rather than relying on valve core depression, as complete core removal provides unobstructed air flow path and visual confirmation of deflation completion. Deflation must continue until no further air release is audible or detectable at valve stem, typically requiring 5-15 minutes depending on tyre size and valve stem flow capacity. After audible deflation ceases, verification procedures include multiple complementary checks: physical depression of tyre sidewalls using mechanical leverage should cause visible tyre collapse indicating absence of internal pressure; insertion of tyre wedge or tyre iron between tyre bead and rim should encounter no resistance from pressurised bead tension; and waiting period of minimum 10 minutes after initial deflation before disassembly provides time for trapped air in tyre voids to migrate and release. For dual tyre configurations, both tyres must be independently deflated with verification each tyre contains no residual pressure before either wheel is removed. Bead breaking procedures using hydraulic bead breakers or mechanical lever tools forcefully separate tyre beads from rim flanges, releasing any remaining trapped air pockets and providing definitive confirmation deflation is complete. Some modern tyre service vehicles include central tyre inflation system (CTIS) connections enabling rapid deflation through large-diameter hoses—when available these provide faster deflation than valve stem release and should be utilised preferentially. Documentation of deflation completion including time and worker identification provides accountability and prevents rushed disassembly before adequate deflation verification.

Implementation

1. Develop tyre deflation standard procedure documenting step-by-step deflation sequence including valve core removal, waiting period duration, and verification checks required before proceeding to rim disassembly 2. Provide all tyre service personnel with valve core removal tools, tyre pressure gauges, and bead breaking tools, ensuring proper equipment availability prevents workers from bypassing deflation steps 3. Establish minimum 10-minute waiting period after audible air release ceases before permitting rim disassembly, enforced through documented deflation completion times recorded on work orders 4. Train personnel in proper deflation verification techniques including sidewall depression testing, bead separation testing, and recognition of incomplete deflation indicators 5. Implement mandatory double-check procedure where second worker independently verifies deflation completion before disassembly commences, providing redundant verification preventing errors 6. Install prominent warning signage at tyre service locations stating 'DANGER - Verify Complete Deflation Before Rim Disassembly - Residual Pressure Causes Fatal Rim Explosions' 7. Conduct workplace observations of tyre service operations verifying deflation procedures are consistently followed, providing immediate corrective feedback when shortcuts are observed 8. Investigate and document any instances where workers commence disassembly before complete deflation, treating as serious safety violations requiring retraining or disciplinary action preventing recurrence

Mechanical Handling Equipment for Heavy Components

Engineering

Provide and mandate use of mechanical handling equipment eliminating manual lifting and moving of heavy tyre and wheel components exceeding safe manual handling limits, typically any component exceeding 25 kilograms requires mechanical assistance. Purpose-designed tyre handling equipment includes overhead gantry cranes rated for 500-2,000 kilogram capacity with pneumatic or electric hoists enabling controlled vertical lifting and horizontal movement of complete wheel assemblies or individual tyres, mobile hydraulic tyre manipulators featuring articulated arms with pneumatically-actuated tyre clamps enabling single operator to lift and position tyres without manual load bearing, forklift-mounted tyre handling attachments with adjustable forks or clamps designed specifically for tyre service applications, and mobile engine hoists adapted with tyre-specific lifting slings or chains for lifting and positioning. All lifting equipment must have rated capacity exceeding maximum loads being handled, with capacity clearly marked on equipment and verified through certification or testing. Proper rigging accessories including certified lifting slings, shackles, and spreader bars distribute loads safely and prevent point-load damage to tyres or rim components. For lighter components including small truck tyres or rim components, wheeled trolleys or carts enable workers to roll components rather than carrying, reducing manual handling strain. Tyre cradles or saddles provide secure support for tyres during inflation, inspection, and storage, preventing tyres from falling or rolling and enabling optimal working height without awkward bending. Mobile workshop vehicles servicing equipment in field locations should carry portable lifting equipment including chain blocks, come-alongs, or portable gantries enabling mechanical lifting even at remote service locations. Planning tyre service operations to occur in workshop locations with fixed overhead cranes provides optimal lifting capability, though field service situations require portable mechanical handling solutions maintaining equivalent manual handling protection.

Implementation

1. Install overhead gantry cranes or jib cranes in primary tyre service workshop areas, sized for maximum tyre and wheel assembly weights in fleet (typically 1,000-2,000kg capacity for construction equipment) 2. Procure mobile hydraulic tyre manipulators or forklift-mounted tyre handling attachments providing portable lifting capability for field service operations or multiple service bay use 3. Provide wheeled trolleys, rolling carts, and tyre cradles in adequate quantities enabling workers to transport and position tyres without manual carrying for all common tyre sizes 4. Supply certified lifting rigging including slings, shackles, and spreader bars in sizes appropriate for tyre service applications, with periodic inspection and load testing maintaining certification 5. Train all tyre service personnel in proper mechanical lifting equipment operation including rigging procedures, load centre calculations, and safe working load limits 6. Establish procedural requirement prohibiting manual lifting of complete wheel assemblies or tyres exceeding 25 kilograms, mandating mechanical handling for all heavy components 7. Conduct workplace observations verifying mechanical handling equipment is consistently used, investigating and addressing any instances of workers manually handling heavy components 8. Maintain mechanical handling equipment through periodic inspection and maintenance ensuring reliable operation and preventing equipment failures that might incentivise workers to attempt manual handling

Rim Component Inspection and Rejection Criteria

Administrative

Implement systematic rim component inspection procedures identifying corrosion, cracks, deformation, or damage requiring component replacement before reassembly and inflation, preventing structural failures during service. Inspection procedures address both dismounted rim inspection during tyre service and periodic in-service inspections during routine equipment maintenance. Dismounted rim inspection occurs when rims are completely disassembled with all components including rim base, side rings, lock rings, and valve stems individually examined. Visual inspection identifies obvious damage including cracks, severe corrosion with metal loss exceeding 2mm, significant deformation from impacts, and worn or damaged lock ring grooves. Wire brush cleaning of corrosion scale and dirt from rim surfaces enables inspection of actual metal condition beneath surface contamination. Dimensional inspection using callipers or depth gauges verifies rim groove depths remain within specifications, as worn grooves may not adequately retain lock rings. Lock rings are particularly susceptible to damage and corrosion, requiring replacement whenever split ring ends show signs of fatigue cracking, corrosion damage, or deformation. Valve stems require inspection verifying cores move freely, bodies show no cracks or elongation, and rubber mounting grommets remain pliable without cracking or dry-rot. Non-destructive testing including dye penetrant or magnetic particle inspection can identify subsurface cracks not visible during visual inspection, recommended for rims showing any suspicious indications. Rejection criteria established in procedures provide objective determination when components must be replaced rather than relying on worker judgment—criteria include any visible cracks regardless of length, corrosion pitting exceeding 2mm depth, deformation exceeding 5mm deviation from true circular form, and lock ring groove wear exceeding manufacturer specifications. Rejected components must be physically destroyed (cut or crushed) preventing inadvertent reuse by workers under pressure who might consider 'just using it one more time' despite known defects.

Implementation

1. Develop rim component inspection procedure documenting inspection sequence, specific areas requiring examination, rejection criteria, and required actions for rejected components 2. Provide inspection tools including wire brushes for cleaning, inspection lights for visual examination, callipers for dimensional verification, and magnifying glasses for crack detection 3. Train personnel in systematic rim inspection techniques including how to identify cracks, corrosion severity assessment, and dimensional verification procedures 4. Establish clear rejection criteria that any crack, corrosion exceeding 2mm depth, or deformation exceeding 5mm requires immediate component replacement without exception 5. Implement component rejection documentation requiring supervisor notification and replacement part ordering before service continues, preventing reuse of rejected components 6. Physically destroy rejected rim components by cutting or crushing, marking clearly as 'SCRAP - REJECTED FOR SAFETY' preventing inadvertent reuse 7. Maintain rim component replacement records tracking failure modes, service life, and rejection reasons, identifying trends indicating premature failure requiring investigation 8. Schedule periodic rim inspections independent of tyre service, inspecting all fleet wheels annually to identify developing damage before emergency tyre service requiring use of deteriorated components

Vehicle Stabilisation and Support Procedures

Engineering

Establish comprehensive vehicle stabilisation procedures ensuring equipment remains secure and stable throughout wheel removal and installation operations, preventing vehicle collapse causing crush injuries to workers. Stabilisation commences with vehicle positioning on firm level ground, engaging parking brakes, placing transmission in park or engaging gear, and chocking wheels remaining on ground preventing vehicle rolling. For mobile equipment with hydraulic booms or buckets (excavators, loaders), booms must be lowered to ground providing additional stability point and preventing hydraulic cylinder drift causing equipment movement. Engine shutdown and key removal prevents accidental engine start causing hydraulic system activation. Vehicle raising uses appropriate capacity jacks positioned under manufacturer-specified lifting points documented in equipment service manuals—improvised lifting under random undercarriage locations can damage components or lift under weak areas causing structural failure. Hydraulic jacks provide initial lifting capability but are inadequate for supporting raised vehicles during work periods—once raised, vehicles must be lowered onto mechanical supports including axle stands (jack stands) rated for vehicle weight or purpose-built support cribs constructed from heavy timber or steel. Multiple support points distributed under vehicle chassis provide stable support preventing tipover—minimum three points for vehicles with symmetrical weight distribution, four or more points for large equipment or asymmetrical loading. Support positioning must maintain vehicle stability considering load distribution during wheel removal reducing weight on one side. Ground bearing capacity beneath supports must be adequate preventing support settling—timber mats or steel plates beneath supports distribute loads on soft ground. Exclusion zones surrounding raised vehicles prevent workers from positioning beneath suspended masses unless specifically required for wheel bolt access, with strict minimisation of time workers spend in crush zones beneath equipment. Warning barriers and signage around raised equipment alert other workers to instability hazards and restricted access.

Implementation

1. Provide appropriate capacity hydraulic jacks for all equipment sizes in fleet, typically 10-50 tonne capacity for construction equipment, with capacity clearly marked and verified through certification 2. Supply adequate quantities of mechanical support stands (axle stands) or support cribs rated for maximum equipment weights, positioned at service locations and carried on mobile service vehicles 3. Develop equipment-specific vehicle stabilisation procedures referencing manufacturer service manuals for correct lifting points and support positioning, documented as posters or laminated cards in service areas 4. Provide timber mats or steel load-spreading plates for use beneath jacks and support stands on soft ground, sized to achieve less than 200 kPa bearing pressure 5. Train tyre service personnel in proper vehicle stabilisation including jack positioning, sequential jacking procedures, support stand placement, and exclusion zone establishment 6. Establish mandatory verification procedure requiring second worker to inspect and confirm vehicle stability before any worker positions beneath raised equipment 7. Deploy physical barriers including barrier tape and witches hats around raised vehicles preventing casual approach by workers unfamiliar with service activities 8. Mount warning signage on raised equipment stating 'DANGER - Raised Equipment - Do Not Enter - Crush Hazard' alerting workers to exclusion zones

Controlled Inflation Procedure with Pressure Monitoring

Administrative

Establish systematic tyre inflation procedures using controlled pressure application with continuous pressure monitoring, enabling detection of bead seating problems or rim assembly issues before reaching dangerous pressure levels. Inflation procedures specify maximum initial inflation pressure typically 170 kPa (25 psi) during bead seating phase, with inflation paused to verify both tyre beads are evenly seated around complete circumference before continuing to working pressure. Inflation rate should be gradual allowing time for visual observation of tyre behaviour—rapid inflation using unregulated air supply can cause pressures to overshoot targets before operator can react. Pressure monitoring using reliable gauges visible during inflation enables operator to observe pressure progression and immediately identify unexpected pressure changes indicating problems. Inflation equipment should include pressure regulator preventing pressure exceeding preset maximum even if air supply is inadvertently left flowing, providing automatic overpressure prevention. Two-stage inflation process separates initial bead seating inflation (to 170 kPa) from final inflation to working pressure (typically 350-900 kPa depending on application), with mandatory inspection after bead seating confirming proper seating before proceeding to final pressure. Inflation must occur within safety cage with operator positioned outside cage observing through cage openings—operator should never enter cage during any phase of inflation process. Some operators attempt seating stubborn beads by placing heavy objects on tyre shoulders forcing beads outward, but this creates projection hazards if objects are dislodged by sudden bead seating and should not be permitted. If bead seating is not achieved after reaching 170 kPa, deflate tyre completely, inspect and clean rim bead seats and tyre beads, apply appropriate bead lubricant, and re-attempt inflation rather than progressively increasing pressure hoping for eventual seating. Working pressure verification after inflation completion confirms final pressure matches specification for equipment operating conditions—overinflation reduces tyre life and increases explosion risk, while underinflation causes excessive heat buildup and structural damage.

Implementation

1. Provide inflation equipment including pressure regulators, relief valves, and accurate pressure gauges enabling controlled inflation monitoring—regulators should be adjustable for initial bead seating pressure (170 kPa) and final working pressure 2. Install inflation pressure gauges in prominent positions outside safety cages enabling continuous monitoring throughout inflation without operator entering hazard zone 3. Develop inflation procedure documenting two-stage process: Stage 1 inflate to 170 kPa and verify bead seating, Stage 2 continue to working pressure only after bead seating confirmation 4. Train personnel in recognising proper bead seating including visual confirmation both beads are uniformly seated around complete circumference with consistent bead positioning relative to rim flange 5. Establish maximum inflation rate limits preventing rapid uncontrolled inflation, typically limiting to 50 kPa per minute enabling adequate observation time 6. Mount inflation procedure placards on or adjacent to safety cages providing quick reference for correct pressure sequences and verification requirements 7. Implement documentation requirement recording inflation pressures and bead seating verification for major tyre services providing evidence correct procedures were followed 8. Conduct periodic calibration of pressure gauges and testing of pressure regulators ensuring accurate pressure monitoring and control throughout service life

Personal protective equipment

Safety Footwear (Steel Toe Caps and Metatarsal Protection)

Requirement: AS/NZS 2210.3:2009 compliant safety boots with steel toe caps and metatarsal guards providing protection from heavy components dropped or rolled onto feet

When: Mandatory for all personnel conducting or observing tyre changing operations. Heavy rim components weighing 50-300 kilograms cause catastrophic foot injuries if dropped. Metatarsal protection extending over instep provides additional protection from rolling tyres or components.

Impact-Rated Safety Glasses with Side Shields

Requirement: AS/NZS 1337.1:2010 compliant safety glasses providing impact protection from flying debris, metal fragments from wire brushing during cleaning, and hydraulic fluid spray

When: Required throughout all tyre service operations particularly during rim cleaning, component disassembly and assembly, and inflation observation. Protects eyes from rim corrosion debris, dirt from tyre surfaces, and potential rim fragments if unexpected failures occur.

Heavy-Duty Work Gloves (Cut and Abrasion Resistant)

Requirement: AS/NZS 2161.2:2005 compliant gloves providing cut resistance from sharp rim edges and abrasion protection from rough tyre and rim surfaces

When: Required during all manual handling of tyres, rims, and components. Protects hands from cuts on rim edges, metal burrs, and embedded debris in tyre treads. Not suitable for power tool operations where glove entanglement risk exists—remove gloves during power tool use.

Hearing Protection (Earmuffs or Earplugs)

Requirement: AS/NZS 1270:2002 compliant hearing protection providing minimum 20dB noise reduction for impact tool operations

When: Mandatory when using pneumatic impact tools for wheel bolt removal and installation, and during bead breaking operations using pneumatic or hydraulic tools generating impact noise exceeding 85dB(A). Protects against progressive hearing damage from repeated high-intensity noise exposure.

High-Visibility Vest

Requirement: AS/NZS 4602.1:2011 compliant high-visibility vest providing visibility in workshop and field service locations

When: Required for field tyre service operations where mobile plant and vehicles operate near service locations. In workshop environments with controlled access, high-visibility clothing may be optional depending on workplace traffic management and lighting conditions.

Face Shield (For Rim Cleaning and Wire Brushing)

Requirement: AS/NZS 1337.1:2010 compliant face shield providing full face protection supplementing safety glasses during high-debris-generation operations

When: Required when using powered wire brushes or grinding wheels to clean corrosion from rims, when heavy rust or scale generates extensive particulate debris. Provides protection beyond safety glasses including cheeks, nose, and chin from flying particles.

Inspections & checks

Before work starts

  • Verify all tyre service personnel hold appropriate competency certifications or training documentation for heavy vehicle and earthmoving tyre service, with evidence of understanding split rim hazards and safety cage requirements
  • Conduct functional check of tyre safety cage including door operation, structural integrity of mesh and framework, and condition of remote inflation equipment confirming cage is serviceable
  • Inspect mechanical lifting equipment including overhead cranes, tyre manipulators, or forklift attachments for current load test certification, operational function, and absence of damage to chains, cables, or hydraulic systems
  • Verify availability of all required tools and equipment including valve core removal tools, bead breaking equipment, torque wrenches, rim inspection tools, and pressure monitoring equipment
  • Check vehicle service information identifying tyre specifications, rim bolt torque values, inflation pressures, and specific service precautions documented by equipment manufacturers
  • Assess work area conditions including firm level ground for vehicle positioning, adequate clearance around safety cage, availability of mechanical handling equipment, and absence of overhead powerlines or obstructions
  • Review service request identifying specific service requirements (tyre replacement, puncture repair, routine inspection) and confirm required replacement tyres or repair materials are available before commencing work
  • Conduct toolbox meeting with all personnel involved in service operation reviewing task sequence, hazard recognition, safety cage use requirements, and emergency procedures if rim explosion or equipment collapse occurs

During work

  • Monitor vehicle stability throughout wheel removal and installation operations, observing support stands for movement, ground subsidence beneath supports, or vehicle listing indicating stability loss requiring immediate work cessation
  • Verify complete tyre deflation through multiple complementary checks including valve stem observation, sidewall depression testing, and bead separation verification before commencing any rim disassembly operations
  • Conduct systematic rim component inspection as disassembly progresses, examining each component for cracks, corrosion, deformation, or damage requiring replacement, with rejected components immediately segregated for destruction
  • Observe proper mechanical handling equipment use throughout service operations, ensuring workers use overhead cranes, tyre manipulators, or trolleys rather than attempting manual lifting of heavy components
  • Monitor tyre inflation within safety cage through remote observation, watching for uneven bead seating, unusual tyre movements, or pressure anomalies indicating assembly problems requiring deflation and reinspection
  • Maintain continuous exclusion zone around raised vehicles preventing unauthorised entry beneath suspended equipment masses creating crush hazards if vehicle collapse occurs
  • Verify correct wheel bolt torque application using calibrated torque wrenches following manufacturer specifications and proper tightening sequence, preventing uneven loading or bolt fatigue from incorrect installation
  • Monitor surrounding work environment for approaching vehicles, equipment movements, or changing conditions requiring work suspension until hazards are eliminated or controlled

After work

  • Conduct final inspection of completed wheel installation verifying wheel bolt torque, valve stem security, absence of rim component damage during installation, and final inflation pressure matches specifications
  • Test drive completed equipment at low speed in controlled area observing for unusual noises, vibrations, or handling characteristics indicating installation problems requiring immediate reinspection before returning to normal operation
  • Lower and stabilise serviced vehicle from raised position using systematic sequence removing support stands, lowering hydraulic jacks, and confirming vehicle rests firmly on all wheels before removing chocks or releasing parking brake
  • Clean and organise service area removing tools, cleaning materials, and rejected components, returning mechanical handling equipment and safety cage to ready condition for next service operation
  • Document service completion including date, equipment identification, tyres replaced or repaired, rim component replacements, torque values applied, final inflation pressures, and personnel conducting work
  • Properly dispose of rejected rim components, worn tyres, and service waste materials following environmental regulations and workplace procedures including segregation of recyclable and hazardous materials
  • Review service operation with all participants discussing any problems encountered, near-miss events, or improvement opportunities for future services, documenting lessons learned for procedure refinement
  • Update equipment maintenance records with tyre service documentation enabling tracking of tyre life, failure modes, and scheduled replacement intervals supporting predictive maintenance planning

Step-by-step work procedure

Give supervisors and crews a clear, auditable sequence for the task.

Field ready
1

Pre-Service Planning and Equipment Preparation

Before commencing heavy vehicle or earthmoving equipment tyre changing operations, conduct comprehensive planning including review of equipment service history identifying previous tyre issues or recurring problems, determination of required replacement tyre specifications matching equipment operating conditions and manufacturer recommendations, verification replacement tyres are available in required sizes and load ratings, and assessment of service location suitability including firm level ground, proximity to lifting equipment and safety cage, and absence of environmental hazards. Verify all tyre service personnel assigned to operation hold appropriate competency certifications or completed training in heavy vehicle tyre service including split rim hazards, safety cage use, and Australian Standards requirements. Assemble required tools and equipment including valve core removal tools, bead breaking equipment, torque wrenches, rim inspection tools including wire brushes and magnifying glasses, mechanical handling equipment including overhead crane or tyre manipulator, and inflation equipment including safety cage with remote controls and pressure monitoring gauges. Conduct functional check of safety cage verifying door operates smoothly, cage structure shows no damage or deterioration, and inflation equipment functions correctly with pressure gauges providing accurate readings. Position safety cage in clear area with adequate surrounding space enabling safe tyre insertion and providing clear evacuation paths if rim explosion occurs during inflation. Prepare work area with proper lighting enabling detailed rim inspection, adequate ventilation for workshop areas, and clear delineation of work zones restricting access to authorised personnel only. Document service commencement on work orders recording equipment identification, initial tyre and rim condition observations, planned service scope, and personnel assigned with competency verification confirmed.

Safety considerations

Planning and preparation prevents rushed improvised procedures causing fatal incidents when workers lack proper equipment and elect dangerous shortcuts. Adequate time allocation for tyre service enables thorough execution of all safety procedures without production pressure compromising safety. Never commence tyre service without confirmed safety cage availability and proper mechanical handling equipment—manual methods and inflation without safety cage are primary factors in fatal tyre service incidents. Competency verification prevents untrained personnel from conducting high-risk tyre service where lack of knowledge about split rim hazards leads to fatal rim explosion incidents.

2

Vehicle Positioning, Stabilisation, and Initial Inspection

Position equipment requiring tyre service in designated service location on firm level ground away from active vehicle traffic routes and with adequate clearance around vehicle for personnel and equipment access. Engage parking brake, place transmission in park position or engage appropriate gear, and shut down engine removing ignition key preventing inadvertent engine start. For mobile equipment with hydraulic positioning systems (excavators, loaders), lower all booms, buckets, or implements to ground providing additional stability and mechanical support. Deploy wheel chocks on tyres opposite wheel being serviced, positioning chocks on both front and rear of tyres preventing forward or rearward vehicle rolling. Conduct initial tyre and wheel inspection identifying puncture location if flat tyre, observing overall tyre condition including tread depth and damage indicating additional service requirements, and visually inspecting wheel rim for obvious damage including cracks, severe corrosion, or deformation. Position appropriate capacity hydraulic jack under manufacturer-specified lifting point located in equipment service manual, verifying jack capacity exceeds vehicle weight and jack is positioned on solid vehicle structural member capable of supporting lifting forces. Place timber mat or steel plate beneath jack on soft ground distributing jack load preventing ground subsidence during raising. Gradually raise vehicle until wheel being serviced is approximately 100-200mm above ground, just sufficient for wheel removal clearance. Position mechanical support stands under additional vehicle structural points providing redundant support, with minimum three support points for overall vehicle stability. Lower vehicle weight onto support stands by gradually releasing hydraulic jack pressure until stands bear full vehicle weight, then remove jack from beneath vehicle eliminating hydraulic support leaving only mechanical supports. Establish exclusion zone around raised vehicle using barrier tape and warning signs preventing unauthorised personnel from entering crush zones beneath suspended vehicle mass.

Safety considerations

Vehicle stabilisation is critical control preventing collapse causing fatal crush injuries. Many incidents occur when workers use inadequate supports including single jack alone without mechanical backup, position supports under weak vehicle structures causing support punch-through, or work on soft ground causing support settling. Never trust hydraulic jack to support vehicle during work period—hydraulic seals leak causing slow descent, creating crush hazard for workers positioned beneath vehicle. Verify support stability before positioning any body part beneath raised vehicle, and minimise time spent in crush zones to absolute minimum required for wheel bolt access. Multiple workers have been killed when raised vehicles collapsed from inadequate stabilisation catching workers beneath suspended masses.

3

Tyre Deflation, Wheel Removal, and Rim Disassembly

Commence tyre deflation by removing valve cap and using valve core removal tool to completely extract valve core from valve stem, allowing unobstructed air flow and visual confirmation of deflation progression. Observe air release monitoring for consistent flow indicating unrestricted deflation, noting any weak air flow suggesting valve stem blockage requiring alternative deflation method. Allow complete deflation continuing until no further air release is audible or detectable, typically 5-15 minutes depending on tyre size and valve passage dimensions. After audible deflation ceases, implement verification procedures including physical sidewall depression using tyre iron or mechanical leverage observing for visible tyre collapse, and insertion of tyre wedge between bead and rim meeting no resistance from internal pressure. Wait minimum 10 minutes after initial deflation completion providing time for residual air in tyre voids to migrate to valve release. For dual wheel configurations, deflate both tyres independently verifying both are completely deflated before proceeding. Position bead breaker tool against tyre sidewall near rim flange and apply breaking force separating tyre bead from rim seat around complete tyre circumference, releasing any trapped air pockets and confirming complete deflation. Remove wheel mounting bolts using impact wrench or breaker bar, loosening bolts in star pattern preventing uneven stress distribution. Position mechanical handling equipment including overhead crane with tyre sling or tyre manipulator adjacent to wheel, connecting rigging to wheel using proper lifting points or tyre clamps. Lift wheel assembly clear of hub using smooth controlled motion, manoeuvring wheel to tyre service area away from vehicle for disassembly operations. Lower wheel assembly onto tyre work stand or robust tyre cradle supporting wheel for subsequent disassembly work. For multi-piece rim assemblies (split rims), systematically disassemble rim components starting with lock ring removal using proper tools including ring pliers or removal hooks, working methodically around rim circumference releasing lock ring from retaining groove. Remove side ring components lifting clear of rim base, then separate tyre from rim base using tyre irons and progressive leverage around tyre circumference. Segregate rim components for individual inspection, cleaning, and assessment.

Safety considerations

Complete deflation verification is critical control preventing catastrophic rim explosions during disassembly. Many fatal incidents occur when workers commence rim disassembly believing tyres are deflated, when residual 50-200 kPa pressure remains sufficient to cause violent explosive separation when rim mechanical interference is broken. Never trust visual tyre appearance or single deflation method—implement multiple redundant verification checks including waiting period, physical testing, and bead breaking before proceeding. Historical incidents include workers killed when using hammers and chisels to separate split rim components from partially deflated assemblies, causing explosive rim separation launching rim rings as projectiles causing instant fatal injuries. Inadequate deflation verification represents highest-risk error in tyre service operations and must be prevented through rigorous adherence to verification procedures regardless of production pressure or worker experience level suggesting 'it's safe to proceed'.

4

Rim and Component Inspection, Cleaning, and Preparation

Conduct systematic inspection of all rim components including rim base, side rings, lock rings, and valve stems, examining for damage requiring replacement before reassembly. Visual inspection identifies obvious defects including cracks visible on surfaces, severe corrosion with substantial metal loss or pitting, significant deformation from impacts distorting rim circular form, and worn or damaged lock ring grooves. Use wire brush and cleaning solvent to remove corrosion scale, dirt, and accumulated debris from rim surfaces, exposing actual metal condition beneath contamination for accurate assessment. Pay particular attention to lock ring grooves inspecting for corrosion pitting, wear causing groove widening, or damage preventing proper lock ring retention. Examine rim bases for cracks commonly initiating at stress concentration points including bolt holes, rim base to rim flange transitions, and areas with previous damage or repairs. Inspect lock rings for cracks at ring ends, corrosion damage particularly in areas bearing against rim grooves, and any signs of permanent deformation. Check valve stems for cracks in metal stems, deteriorated rubber mounting grommets showing cracking or hardness loss, and smooth valve core operation without binding or leakage. Apply dimensional inspection measuring rim groove depths using depth gauge or calliper, comparing to manufacturer specifications and rejecting rims where groove wear exceeds acceptable limits. Use magnifying glass or inspection light to examine suspicious areas where subsurface cracks may be present but not obvious to unaided visual inspection. When any defect meets rejection criteria including any visible crack regardless of size, corrosion depth exceeding 2mm, deformation exceeding 5mm from true circular form, or groove wear beyond specification, immediately reject component and segregate for destruction preventing inadvertent reuse. Order replacement components before proceeding with service, ensuring correct component types and sizes for specific rim configuration. Clean and prepare serviceable components using solvent or degreaser removing all contamination, then apply protective coating to prevent corrosion during storage if components will not be immediately reassembled. Inspect replacement tyre verifying correct size, load rating, and construction type for intended application, checking for manufacturing defects, storage damage, or excessive age (tyres stored more than 5 years may have deteriorated rubber compounds even if never used).

Safety considerations

Rim inspection and component rejection is critical prevention control for rim explosion incidents caused by structural failure of deteriorated components. Many rim failures occur during inflation of apparently serviceable rims where invisible subsurface cracks or internal corrosion cause sudden catastrophic failure under pressure loading. Rejection criteria must be rigidly applied without exception—any crack, severe corrosion, or significant damage requires immediate rejection regardless of 'how much life remains' or production pressure to reuse marginally serviceable components. Components that 'looked okay' have failed explosively killing workers during subsequent inflation, demonstrating visual inspection alone is insufficient and conservative rejection criteria with age-based replacement protocols provide only reliable failure prevention.

5

Tyre Mounting, Rim Assembly, and Component Security Verification

Position tyre on rim base using mechanical handling equipment or rolling assistance, aligning tyre with rim centre and ensuring tyre direction arrows match intended rotation direction if directional tread pattern. Lubricate tyre beads and rim bead seats using approved tyre mounting lubricant (soapy water or commercial tyre lubricant), facilitating bead seating during inflation and preventing tyre and rim damage during mounting. Use tyre irons and progressive leverage to work first tyre bead over rim flange, distributing force around circumference and avoiding concentrated loading that damages beads. Once first bead is positioned inside rim, work second bead over rim flange using similar technique. For multi-piece split rim assemblies, position side ring against tyre inside sidewall ensuring ring seats properly in rim groove with complete circumferential contact. Install lock ring starting at one point and progressively working around circumference, using ring installation tools to compress ring allowing insertion into rim groove. Verify lock ring is fully seated in retaining groove at all points around complete circumference—improper lock ring seating is primary cause of rim explosions during inflation. Some lock rings feature ring gap positions that must be located away from valve stem preventing interference. Double-check all rim components are properly positioned and fully seated before proceeding to inflation. Install new valve stem if old stem shows deterioration, using correct stem length and type for rim configuration. Install valve core ensuring tight seating and testing for air leakage by applying soapy water to valve and observing for bubbles. Position assembled wheel and tyre on tyre dolly or handling equipment and transport to safety cage for inflation operations. Load tyre into safety cage through rear opening, centering tyre in cage and orienting valve stem toward front for access. Close and secure cage door ensuring positive latching that cannot inadvertently open during inflation. Verify remote inflation controls and pressure gauge are functional and properly connected to cage inflation connection.

Safety considerations

Proper rim component assembly particularly lock ring full seating verification is critical prevention control for rim explosion during inflation. Improper lock ring installation where ring appears seated but actually has unsecured sections allows ring to pop out of groove during initial pressurisation causing violent explosive separation. Many fatal incidents occur when workers fail to verify complete lock ring seating, assuming visual appearance indicates proper assembly when in reality critical sections are incompletely engaged. This verification step must not be rushed or assumed—systematic verification of seating around complete circumference is essential and non-negotiable regardless of worker experience or confidence that assembly 'feels right'. If any doubt exists about component seating, disassemble and restart assembly procedures verifying correct seating rather than proceeding with inflation of questionable assembly.

6

Controlled Inflation with Safety Cage and Bead Seating Verification

Position observer outside safety cage with clear view of tyre through cage openings, able to observe tyre behaviour and pressure gauge simultaneously while operating remote inflation controls. Commence initial inflation phase gradually increasing pressure while observing tyre behaviour watching for uneven bead seating, unusual tyre movements, or asymmetric tyre shape indicating assembly problems. Continue initial inflation to maximum 170 kPa (25 psi) monitoring for bead seating events (audible pops indicating beads engaging rim flanges). At 170 kPa or when bead seating sounds are heard, pause inflation and carefully observe tyre through cage openings verifying both tyre beads are uniformly seated around complete tyre circumference with consistent positioning relative to rim flange. Look for circumferential mold line on tyre sidewall near bead which should be parallel to and equidistant from rim flange around entire circumference—variations indicate unseated bead sections requiring deflation and reinspection. If bead seating is uneven or incomplete at 170 kPa, deflate tyre completely, inspect and relubricate bead seats and tyre beads, verify rim components are properly positioned, and re-attempt inflation. Never exceed 170 kPa attempting to force bead seating—if seating does not occur by this pressure, assembly problems exist requiring investigation rather than higher pressures. Once uniform bead seating is verified at 170 kPa, continue inflation to final working pressure specified by equipment manufacturer or tyre placard, typically 350-900 kPa depending on application. Monitor pressure progression using accurate gauge, stopping inflation when target pressure is reached. Allow inflated tyre to stabilise for 2-3 minutes with pressure remaining constant, watching for pressure drop indicating air leakage from valve, bead seal, or punctures requiring investigation. After successful inflation and stabilisation, reduce pressure slightly (approximately 30 kPa) to account for temperature-related pressure increase when tyre returns to service generating heat. Open safety cage door, carefully remove inflated tyre assembly using mechanical handling, and transport to vehicle for installation.

Safety considerations

Safety cage use during all inflation operations is absolute non-negotiable requirement preventing fatal injuries from rim explosions. Every worker must understand that cage is life-saving barrier between them and explosive rim separation hazards, and that convenience-driven decisions to bypass cage for 'quick inflation' cause fatal incidents when unexpected rim failures occur. Many workers killed during tyre inflation were experienced personnel who understood correct procedures but made fatal decision to inflate outside cage believing their experience enabled them to identify when risks were present—rim explosions occur without warning and cannot be predicted through experience or visual assessment. Two-stage inflation procedure with bead seating verification at 170 kPa provides critical checking point identifying assembly problems before reaching destructive pressures that cause catastrophic failures. Never proceed beyond 170 kPa until verified uniform bead seating confirms proper assembly—fatal incidents occur when workers continue pressurisation attempting to force seating when assembly problems exist, eventually causing explosive failures.

Frequently asked questions

What is a split rim and why is it more dangerous than regular single-piece rims?

Split rims (also called multi-piece rims or lock ring rims) are wheel rim assemblies consisting of multiple separate components including rim base, side rings, and lock rings that mechanically interlock to create complete rim assembly holding tyre in position. Unlike single-piece rims used on most passenger vehicles which are manufactured as single continuous units, split rims can be disassembled by removing lock rings allowing tyre mounting and dismounting without specialized tyre machine equipment. This design was developed for large tyres used on trucks, earthmoving equipment, and agricultural machinery where tyre sizes and weights make conventional tyre mounting impractical. Split rim assemblies are inherently more dangerous than single-piece rims because their multi-component construction creates explosion hazards during inflation and dismounting operations. Lock rings that secure rim components together are held in rim grooves by mechanical interference and internal air pressure—if lock rings are not fully seated in grooves during inflation, increasing pressure can cause sudden violent separation where lock rings are launched as projectiles at extreme velocities (documented at 50-150 metres per second in incident investigations). Similarly, if workers attempt rim disassembly before tyres are completely deflated, residual air pressure causes explosive separation when lock rings are removed releasing stored pressure energy. The heavy mass of rim components (typically 10-100 kilograms for rings and 50-300 kilograms for rim bases) creates enormous kinetic energy when accelerated by explosive separation—equivalent to explosive fragmentation injuries documented in military ordnance incidents. Australian Standard AS 4457.1:2007 recognises split rim explosion hazards specifying mandatory safety cage use for all split rim tyre inflation operations, yet fatal incidents continue occurring when workers bypass safety cage use or fail to verify complete deflation before disassembly. Single-piece rims eliminate mechanical separation hazards as rim is continuous structure without removable components, and explosion risks are limited to tyre bead blowoff scenarios which are less severe than split rim component projection incidents. Workers must be able to identify split rim assemblies versus single-piece rims—split rims feature visible lock ring groove around rim circumference and separate side ring components, while single-piece rims have continuous rim flanges without separation joints. When in doubt about rim construction, treat all heavy vehicle and earthmoving equipment rims as split rims implementing safety cage use and complete deflation verification before any service operations.

How can I be certain a tyre is completely deflated before starting to disassemble the rim?

Complete tyre deflation verification requires multiple redundant checks providing high confidence that zero residual pressure remains before commencing rim disassembly operations. Single verification method is inadequate as tyres can appear deflated while retaining hazardous pressure levels—comprehensive verification addresses multiple indicators and uses time delays allowing all trapped air to release. Start verification by removing valve core completely from valve stem using valve core removal tool rather than merely pressing valve pin, as complete core removal provides largest flow path enabling full deflation and visual confirmation of valve interior. Observe air release from valve stem for sustained flow—initial strong flow lasting several minutes is normal for large tyres, but flow should gradually diminish to nothing as deflation completes. Continue deflation until absolutely no air movement is detectable at valve stem by holding hand adjacent or placing tissue paper near valve observing for movement. After audible deflation ceases, wait minimum 10 minutes before proceeding as this delay allows air trapped in tyre void spaces, between tyre plies, or in damaged tyre structures to migrate to valve release path. This waiting period is non-negotiable time control preventing workers from rushing into disassembly before complete pressure equalisation. After waiting period, conduct physical sidewall depression test by applying leverage with tyre iron or pry bar against tyre sidewall—properly deflated tyre should visibly collapse under applied force with no springback resistance. Attempt to insert tyre wedge or similar blunt tool between tyre bead and rim—insertion should meet zero resistance if internal pressure is absent, while residual pressure creates resistance preventing insertion. Next perform bead breaking operations using hydraulic bead breaker or mechanical leverage tools forcefully separating both tyre beads from rim sealing surfaces around complete tyre circumference—this physical separation releases any remaining trapped air pockets and provides definitive confirmation no pressure remains. Bead breaking should occur easily without excessive force if tyre is truly deflated. For dual wheel configurations where two tyres share common hub, deflate both tyres independently using same verification procedures for each. Do not assume deflation of one tyre ensures second is also deflated—pressure can migrate between tyres through valve connections or through wheel hub cavities connecting wheel spaces. Some equipment features central tyre inflation systems (CTIS) connecting all tyres through manifolds—on CTIS-equipped equipment, verify inflation system is depressurised and disconnected before commencing service. If tyre will not deflate through normal valve stem procedures suggesting valve core blockage or seized valve mechanism, implement alternative deflation including drilling small hole in tyre sidewall well away from rim and working area (minimum 200mm from rim) allowing controlled pressure release. Mark the drill location and patch during tyre repair. Document deflation completion on work orders recording method used, verification checks performed, and workers' confirmation deflation is complete. This documentation provides accountability and prevents one worker assuming another has completed deflation when responsibility is ambiguous. Train all tyre service personnel that assumption tyres are deflated based on visual appearance or single check is fatal error—complete verification using multiple methods and time delays is only acceptable approach preventing explosive rim separation incidents during disassembly.

Our site doesn't have an engineered safety cage for tyre inflation. What alternatives are acceptable?

Australian Standard AS 4457.1:2007 specifies mandatory safety cage use for all heavy vehicle and earthmoving equipment tyre inflation operations without exception, and no alternatives to engineered safety cages are acceptable for ongoing operational use. The standard's absolute cage requirement reflects the severity and preventability of rim explosion incidents—safety cages engineered to contain explosive rim separation provide only reliable protection preventing fatalities, and any inflation approach without cage protection exposes workers to unacceptable fatal injury risks that are readily preventable through proper equipment use. Sites lacking safety cages must immediately procure or construct cages before any tyre inflation operations continue. In interim period before cage acquisition (maximum 2-3 days for emergency procurement of commercial cages), absolutely no tyre inflation work should occur other than emergency temporary inflation using extreme distance procedures detailed below. Long-term absence of safety cages represents serious WHS compliance failure and regulatory enforcement action including prohibition notices and prosecution would be expected outcomes of safety regulator inspection. For emergency temporary inflation in absolute emergency situations where operational necessity requires immediate tyre service before permanent cage installation (breakdown requiring urgent repairs to enable equipment operation), implement extreme distance inflation procedures: Position tyre assembly minimum 50 metres from any workers, buildings, or equipment using remote inflation lines long enough to reach from worker position to tyre. Use regulated air supply with pressure relief valve preventing overpressure beyond target inflation. Establish exclusion zone with physical barriers and warning signage preventing anyone approaching within 50 metres during inflation. Operator positioned behind substantial barrier (earth berm, heavy equipment, concrete structure) uses remote controls to inflate tyre while observing through binoculars or camera system from protected position. Inflate to maximum 170 kPa, then approach tyre to verify bead seating only after 30 minute waiting period allowing energy dissipation if delayed rim separation occurs. If bead seating is satisfactory, retreat to protected position and continue inflation to working pressure. This extreme distance method provides inferior protection compared to safety cages and should only be used once or twice in genuine emergencies before proper safety cage is procured—using extreme distance methods as standard practice is unacceptable risk management. For permanent solution, sites must procure commercial engineered safety cages meeting AS 4457.1:2007 requirements, available from industrial safety equipment suppliers with costs ranging $5,000-15,000 depending on capacity and features. Alternatively, sites can fabricate custom safety cages designed by qualified structural engineers and load-tested to verify containment capability—site-fabricated cages must demonstrate equivalent protection to commercial cages including strength to contain 200 kilogram mass at 10 metres per second impact velocity, structural design using minimum 10mm steel plate or equivalent, three-sided enclosure with rear opening for tyre insertion, and operational features including inflation controls positioned outside cage and pressure monitoring systems. Safety cage investment is small fraction of cost of single fatal rim explosion incident considering workers' compensation, business interruption, equipment damage, regulatory penalties, and reputational consequences. Budget constraints do not justify continued inflation without safety cage—work must cease until proper equipment is provided. Sites conducting frequent heavy vehicle or earthmoving equipment operations should install safety cages as standard workshop equipment providing reliable safe inflation capability for decades of service. Regular safety cage maintenance including structural integrity inspection, door operation verification, and inflation system checks ensures ongoing protection throughout service life.

What training and competency requirements apply to workers conducting heavy vehicle tyre changing?

Workers conducting heavy vehicle and earthmoving equipment tyre changing must demonstrate competency in recognising and managing specific hazards including split rim explosion risks, stored energy from pressurised tyres, manual handling of heavy components, and vehicle stabilisation procedures. Competency can be demonstrated through formal qualifications, structured workplace training, or combination approaches providing equivalent knowledge and skills. National competency unit AURKTJ011 'Remove, inspect and fit earthmoving and off-the-road tyres' defines comprehensive competency requirements including identifying tyre service requirements, safely deflating tyres and removing wheels, inspecting tyres and wheels for serviceability, mounting tyres using correct procedures, inflating tyres using safety cages, and fitting wheels to equipment using correct torque. This competency is delivered through registered training organisations offering Certificate II or III in Automotive qualifications with heavy vehicle or off-road tyre service specialisations. Training duration ranges from several days for experienced workers seeking formal recognition through recognition of prior learning, to several weeks for workers new to heavy vehicle tyre service requiring supervised practical experience developing competency. Workplace-based training programs can provide equivalent competency through structured approach combining theoretical instruction, supervised practical experience, and competency assessment. Theoretical training must cover Australian Standards requirements (AS 4457.1 and AS 4457.2), split rim construction and explosion hazards, complete deflation verification procedures, rim component inspection and rejection criteria, safety cage operation and inflation procedures, mechanical handling techniques for heavy components, vehicle stabilisation and support procedures, and emergency response for rim explosions or equipment collapse. Duration of theoretical training should be minimum 8-16 hours depending on worker experience. Practical training requires supervised hands-on experience conducting all tyre service operations under observation of competent supervisor or mentor, progressively building from basic tasks (deflation, wheel removal) through complex operations (rim disassembly, component inspection, reassembly, and inflation). Competency assessment verifies workers can independently conduct tyre service operations safely including demonstrating complete deflation verification procedures, correctly identifying damaged rim components requiring rejection, properly assembling multi-piece rim components with correct lock ring seating, operating safety cage and inflation equipment, and responding appropriately to abnormal conditions indicating problems. Assessment should include both written knowledge testing and practical observation of work performance in realistic service scenarios. Refresher training should occur annually or following procedural changes, covering incident case studies demonstrating consequences of procedural shortcuts, updates to Australian Standards or workplace procedures, and reemphasis on absolute requirements including safety cage use and deflation verification. Some organisations implement tiered competency levels distinguishing between workers authorised only for basic tyre service under direct supervision, intermediate workers authorised for routine services with general supervision, and fully qualified workers authorised for complex services including split rim assemblies and field service operations. Documentation of competency including training records, competency assessment outcomes, and authorisation to conduct tyre service independently provides evidence meeting WHS obligations. Maintain individual training files for all tyre service personnel including initial qualification documentation, workplace familiarisation records, competency assessments, and refresher training completion. Verify competency of all tyre service contractors before permitting site access, requesting evidence of formal qualifications or equivalent workplace competency assessment. Competency verification is PCBU responsibility and cannot be delegated—assumptions that workers 'must be competent because they've been doing it for years' are inadequate and have resulted in fatal incidents when workers with long experience lacked understanding of specific hazards and elected dangerous shortcuts under production pressure.

How should rim components be inspected and what defects require replacement rather than continued use?

Systematic rim component inspection identifies damage requiring component replacement before reassembly preventing structural failures during subsequent inflation and service. Inspection addresses all rim components including rim base, side rings, lock rings, valve stems, and wheel mounting bolts examining for multiple degradation modes including cracks, corrosion, deformation, and wear. Start inspection with thorough cleaning removing all corrosion scale, accumulated dirt, grease, and debris using wire brushes and solvent cleaning, exposing actual metal surfaces beneath contamination enabling assessment of true component condition. Visual inspection conducted in good lighting conditions using magnifying glass for detailed examination identifies surface cracks appearing as fine lines or opened gaps in metal, corrosion pitting showing as pockmarks or craters in metal surfaces particularly in areas exposed to moisture accumulation, severe rust with substantial metal loss creating rough textured surfaces or through-thickness perforations, deformation from impacts appearing as dents or bent flanges distorting circular rim form, and lock ring grooves showing wear indicated by widening or depth reduction compared to original specifications. Cracks commonly initiate at stress concentration points including wheel bolt holes where cyclic loading creates fatigue damage, rim base to rim flange transition areas with sharp geometry changes, areas with previous mechanical damage including impact marks or welded repairs, and lock ring ends subject to bending stress during installation and removal. Critical crack inspection focuses on these high-stress areas using inspection techniques including visual examination with magnifying glass (minimum 4x magnification) identifying cracks as fine dark lines contrasting with cleaned metal surfaces, and dye penetrant or magnetic particle non-destructive testing for subsurface cracks not visible during visual inspection. Corrosion assessment evaluates pitting depth using depth gauges, measuring deepest pit dimensions comparing to 2mm rejection threshold, and evaluates overall corrosion extent determining whether localized corrosion in non-critical areas versus widespread deterioration affecting structural integrity. Severe corrosion particularly in lock ring grooves preventing proper component seating requires rejection even if measured pit depth remains below threshold. Deformation assessment using straight edges, radius gauges, or dimensional templates compares rim circular form to ideal geometry, measuring deviations at multiple circumferential positions. Deformation exceeding 5mm from true circular form requires rejection as distorted rims create uneven stresses during inflation and prevent proper tyre bead seating. Lock ring groove inspection includes dimensional measurement verifying groove depth and width remain within manufacturer specifications, as worn grooves may not adequately retain lock rings allowing dislodgement during service. Some organisations implement ultrasonic thickness testing measuring remaining metal thickness in corroded areas, particularly useful when external corrosion appearance suggests severe damage but extent of through-thickness metal loss is uncertain. Valve stem inspection verifies valve core moves freely without binding or excessive play, valve stem bodies show no cracks or deformation, rubber mounting grommets remain pliable without cracking or hardening, and valve stem length is adequate for rim depth enabling proper valve cap installation. Rejection criteria established in workplace procedures must provide clear unambiguous determination for component disposition including any visible crack regardless of length requiring immediate rejection—cracks propagate under cyclic loading and no crack is acceptable, corrosion pitting depth exceeding 2mm requires rejection—deeper pitting significantly reduces remaining metal strength, deformation exceeding 5mm from true circular form requires rejection—distorted rims create dangerous uneven stresses, lock ring groove wear reducing groove depth below minimum specification requires rejection—worn grooves cannot reliably retain lock rings, and any lock ring showing cracks at ring ends requires rejection—these high-stress areas commonly fail during service. Age-based rejection criteria supplement condition inspection, with some organisations implementing maximum service life limits (10-15 years for rim bases, 5-7 years for lock rings) recognising that metal fatigue develops even in absence of visible damage. Rejected components must be physically destroyed by cutting or crushing preventing inadvertent reuse by workers under production pressure who might consider 'using it one more time' despite known defects. Paint or permanently mark rejected components 'REJECTED FOR SAFETY - DO NOT USE' during period between rejection and destruction. Document rim inspection outcomes on inspection forms recording component identification, inspection date, inspector name, defects identified, and disposition decision (approved for service or rejected for replacement), maintaining records demonstrating systematic inspection and prompt rejection of unserviceable components. When inspection identifies questionable areas where rejection determination is uncertain, adopt conservative approach rejecting components rather than taking risk—component replacement cost is tiny fraction of consequences if questionable component fails explosively during subsequent inflation.

What emergency procedures should be followed if a rim explosion occurs during tyre service?

Rim explosion incidents during tyre service require immediate emergency response prioritising injured worker first aid, scene security preventing additional casualties, and emergency service notification ensuring rapid professional medical intervention. If rim explosion occurs despite safety cage use and procedures designed to prevent such incidents, immediate actions focus on worker safety and emergency medical response. First, immediately stop all inflation operations and ensure no additional personnel approach safety cage or surrounding area until situation is assessed and controlled. If explosion occurred outside safety cage contrary to procedures creating debris field and injury risks, establish initial exclusion perimeter minimum 20 metres radius around incident location preventing additional workers from entering hazard zone potentially containing projected rim components, damaged equipment creating ongoing hazards, or injured workers requiring immediate but cautious approach. Assess casualties from protected position observing from distance whether any workers are visible and their condition—do not rush into incident area without first assessing ongoing hazards including unstable equipment, pressurised air hoses whipping under residual pressure, or secondary explosion risks from remaining pressurised tyres. If casualties are observed and immediate life-threatening conditions are apparent (unconsciousness, significant bleeding, entrapped beneath equipment), designate one worker to immediately call emergency services (000) reporting tyre service incident with explosion injuries, providing specific location, number of casualties, and nature of injuries known. Second responder approaches casualty cautiously watching for ongoing hazards, providing immediate first aid focusing on life threats including controlling severe bleeding with direct pressure using available cloth materials, maintaining airway and breathing for unconscious casualties using recovery position or rescue breathing, preventing shock by keeping casualty warm and reassured, and stabilising suspected spinal injuries preventing movement until paramedics arrive. Do not attempt to move casualties unless immediate danger (fire, additional explosion risk, unstable equipment collapse threat) requires evacuation to safer location, in which case move using spinal precautions if possible. Third responder secures incident scene deploying physical barriers or assigning personnel to prevent unauthorized entry, accounting for all personnel verifying no missing workers may be in hazard area, gathering witness statements from personnel observing incident for subsequent investigation, and preserving evidence photographing equipment position, rim component locations, and incident scene condition before disturbance. If casualties are entrapped beneath equipment or heavy rim components, do not attempt rescue without adequate equipment and personnel—improper rescue attempts create additional casualties when equipment collapses or shifts during rescue. Request specialized rescue resources including heavy rescue trucks with airbags and cribbing capable of safely lifting heavy equipment from casualties, with fire service heavy rescue teams typically providing these capabilities. For conscious casualties with significant injuries, provide reassurance and comfort while awaiting professional medical response, monitoring vital signs and consciousness level, and recording any changes in condition communicated to incoming paramedics. After casualties are evacuated and emergency medical phase concludes, implement incident investigation retaining all equipment and components in as-found condition for examination, interviewing all witnesses documenting incident sequence and causal factors, examining rim components for defects or assembly errors contributing to explosion, and reviewing procedures to identify prevention opportunities for similar future incidents. Notify regulatory authorities as required for serious injuries including WorkSafe or equivalent state WHS regulator for injuries requiring hospitalization or resulting in fatalities, preserving incident scene until regulator inspection if serious outcome incident. Conduct comprehensive investigation identifying root causes which commonly include inflation without safety cage use, inadequate deflation verification before rim disassembly, improper rim component assembly with unseated lock rings, use of damaged deteriorated rim components, or overpressure from unregulated inflation equipment. Implement corrective actions preventing recurrence including immediate procedural reinforcement, equipment upgrades, enhanced training, or operations suspension until satisfactory controls are established. Provide psychological support for workers involved in or witnessing incident, recognising traumatic nature of serious injury incidents and offering employee assistance program counselling to affected personnel. Review incident outcomes with all tyre service personnel ensuring lessons learned are understood and reinforcing absolute importance of following safety procedures including safety cage use and deflation verification. Fatal and serious injury tyre service incidents are preventable through consistent application of established controls—incidents represent system failures where procedures were not followed, equipment was inadequate, or supervision was insufficient, requiring organizational learning and improvement rather than attributing solely to individual worker error.
